The 1803617 is a six-position green pluggable PCB terminal block featuring tin-plated solder contacts, a polyamide insulator, and an M2 screw connection. This MC 1.5/6-ST-3.81 terminal block offers fully developed contact geometries and surfaces, accommodating wire sizes from 28 to 16 AWG. It provides a generously dimensioned wiring space, a parallel plug-in direction aligned with the conductor axis, and a low-profile design. The terminal block includes a 7 mm stripping length, an internal cylindrical gauge (A1), and has a UL94V-0 flammability rating, making it suitable for industrial applications.
