Schneider Electric ZB4BV6 industrial light block
The ZB4BV6 light block with body and fixing collar is designed for BA9s bulbs, supporting voltages up to 250V. It features screw clamp terminals for secure wiring, with a compact 30mm width, 47mm height, and 37mm depth. Made from Zamak, it conforms to multiple safety standards including EN/IEC 60947 series, UL 508, and CSA C22.2 No 14. It offers robust vibration and shock resistance, with an 18-month warranty, making it ideal for industrial automation and panel lighting applications.
Schneider Electric ZB4BV6 industrial light block Specifications:
- Material: Zamak
- Rated Supply Voltage: 250V
- Light Source: BA9s bulb, not included
- Overall Dimensions: Width 30mm, Height 47mm, Depth 37mm
- Connection Type: Screw clamp terminals <= 2 x 1.5 mm? and >= 1 x 0.22 mm?
- Rated Insulation Voltage: 600V
- Impulse Withstand Voltage: 6 kV
- Tightening Torque: 0.8 to 1.2 N.m
- Vibration Resistance: 5 gn
- Shock Resistance: 30 g (18 ms), 50 g (11 ms)
- Environmental Temperature: -40°C to +70°C
- Protection Class: IEC 60536
- Standards: EN/IEC 60947-5-1, EN/IEC 60947-5-4, EN/IEC 60947-1, UL 508, CSA C22.2 No 14
- Certifications: UL, CSA, RINA, GL, DNV, BV, Lloyd’s Registry
- Mounting Hole Diameter: 22.5 mm, minimum 30 mm panel cut-out
- Connections: Screw clamp, plug-in connectors, Faston
- Durability: Vibration and shock resistant, 18 months warranty
Buy the Schneider Series Harmony XB4 Light Block: ZB4BV6
Order the Schneider ZB4BV6 light block online today to ensure durable and precise lighting solutions for your electrical panels. Crafted with Zamak, it offers secure screw clamp connections, robust vibration and shock resistance, and conforms to international safety standards. Its compact size makes installation easy in various industrial control applications, and the 18-month warranty guarantees reliable performance. Purchase online now to enhance your automation setup with this high-quality, industrial-grade lighting component.
Get Schneider ZB4BV6 today—designed for reliable panel lighting in industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4BV6?
You can click on the BUY or RFQ button to purchase ZB4BV6 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4BV6?
You can download the ZB4BV6 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4BV6?
Schneider Electric
