Schneider Electric ZBVB4 Industrial LED Indicator
The ZBVB4 is a durable 24VAC/DC red LED indicator light designed for Ø22mm pushbutton heads. It features a steady signal with a protected LED light source and an integral LED bulb base. The light block is front-mounted with screw clamp terminals for secure connections. It is suitable for industrial signaling applications, offering a service life of 100,000 hours at rated voltage and 25°C. Certified by CSA and UL, it withstands electromagnetic interference and transient surges, making it reliable for demanding environments.
Schneider Electric ZBVB4 Industrial LED Indicator Specifications:
- Supply Voltage: 19.2...30 V DC, 21.6...26.4 VAC, rated 24 V
- Light source: Protected LED, Red color
- Connection: Screw clamp terminals, <= 2 x 1.5 mm? with cable, >= 1 x 0.22 mm? without cable
- Service life: 100000 hours at 25°C
- Mounting: Front mounting
- Protection: IP20 IEC 60529
- Ambient Temperature: 0...158 °F (-40...70 °C)
- Standards: EN/IEC 60947-5-4, UL 508, CSA C22.2 No 14
- Certification: UL Listed, CSA
- Tightening Torque: 0.8...1.2 N.m
- Resistances: Fast transients 2 kV IEC 61000-4-4, Electromagnetic fields 9.14 V/m IEC 61000-4-3
- Electrostatic Discharge: 6 KV contact, 8 KV air IEC 61000-4-2
- Environmental: Suitable for storage and operation 0...158 °F (-40...70 °C)
- Weight: 0.04 Ib (0.017 kg)
- Standards compliance: EN/IEC 60947-5-4, EN/IEC 60947-5-5, UL 508, CSA C22.2 No 14
Buy the Buy Schneider Electric Light Block ZBVB4 Part Number ZBVB4 Online
Enhance your control system with the Schneider Electric ZBVB4 LED indicator designed for Ø22mm pushbutton heads. Featuring a steady red LED light source, front mounting, and screw clamp terminals, it ensures reliable signaling in demanding environments. With a service life of 100,000 hours, certified by UL and CSA, and resistant to transients and electromagnetic interference, this indicator is ideal for industrial automation, machinery, and control panels. Easily integrate and purchase online for quick deployment and peace of mind.
Get Schneider Electric ZBVB4 today—built for industrial signaling with long-lasting LED performance and reliable front mounting terminals.
Frequently Asked Questions
Where can I buy Schneider Electric ZBVB4?
You can click on the BUY or RFQ button to purchase ZBVB4 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZBVB4?
You can download the ZBVB4 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZBVB4?
Schneider Electric
