3M 5612MM Polyester Film Electrical Tape
3M Polyester Film Electrical Tape 56 is a versatile electrical tape designed for layer insulation and coil cover applications. Featuring a 1-mil yellow polyester film backing and a thermosetting rubber adhesive, this tape provides excellent electrical properties and durability. It is UL recognized, RoHS compliant, and suitable for use in environments up to 130°C (266°F). The tape's adhesive coating is smooth and uniform, ensuring consistent performance and ease of application. It is available in standard and custom widths and lengths, making it a flexible solution for various electrical insulation needs.
3M 5612MM Polyester Film Electrical Tape Specifications:
- Adhesive: Thermosetting Rubber
- Backing: Polyester Film
- Backing Thickness: 1.0 Mil
- Total Thickness: 2.3 mils (0,058 mm)
- Color: Yellow
- Temperature Class: 130°C (266°F)
- Dielectric Breakdown: 5,000 Volts
- Insulation Resistance: >1 x 106 (megohms)
- Breaking Strength: 25 lbs./in. (44 n/10 mm)
- Elongation: 100 (%)
- Electrolytic Corrosion Factor: 1.0
- Adhesion to Steel: 50 oz./in. (5,5 n/10 mm)
- Shelf Life: 5 years
Buy the 56 12MM 3M Polyester Film Electrical Tape | myMectronic
Purchase 3M Polyester Film Electrical Tape 56 securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy 3M 5612MM?
You can click on the BUY or RFQ button to purchase 5612MM from an authorized 3M distributor.
How do I troubleshoot issues or seek technical support for part 5612MM?
You can download the 5612MM datasheet or visit the 3M website for support.
Who is the manufacturer of 5612MM?
3M
