3M 770020100SF Datasheet & Stock
The 3M 7700/20 100'SF is a 20-conductor, round, flat, controlled impedance ribbon cable. It features 30AWG solid tin-plated copper conductors spaced at 0.025 inches (0.635mm). The cable is designed for high-speed data transmission, supporting up to 14Gbps when terminated with an IDC connector and up to 20Gbps when used as a cable only. It is flexible and foldable, making it suitable for tight spaces with minimal performance impact. The insulation includes a polyolefin core laminated with a flexible foil covering to maintain a controlled impedance of approximately 95 ohms (±5 ohms). The cable offers low differential insulation loss (<3dB/m at 2.5GHz), withstands voltages up to 750VAC, and operates within a temperature range of -20°C to 80°C. Constructed with 30AWG solid tinned copper conductors, it also features an aluminum foil and polyester shield for improved performance. Length is 100 feet, suitable for applications in industrial, communication, networking, automated test equipment, and wire-to-board connections. It supports programmable differential pairs, grounds, and power connections.
Frequently Asked Questions
Where can I buy 3M 770020100SF?
You can click on the BUY or RFQ button to purchase 770020100SF from an authorized 3M distributor.
How do I troubleshoot issues or seek technical support for part 770020100SF?
You can download the 770020100SF datasheet or visit the 3M website for support.
Who is the manufacturer of 770020100SF?
3M
