AMPHENOL PCD M2430815F Environmental Connector
The M2430815F is a high-quality environmental D*D series connector designed for aerospace and ground support applications. It features a rugged aluminum shell with cadmium plating and yellow chromate coating for corrosion resistance. Contacts are available in solder pot and crimp types, both gold plated over nickel, accommodating up to #20 AWG stranded wire. The connector offers excellent vibration, moisture resistance, and environmental sealing. It supports high altitude operation up to 70,000 feet, with test data indicating superior insulation resistance, low contact voltage drop, and reliable contact separation force, ensuring durability in extreme conditions.
AMPHENOL PCD M2430815F Environmental Connector Specifications:
- Shell Material: Aluminum, cadmium plated with yellow chromate coating
- Contacts: Copper alloy, gold plated over nickel, solder pot and crimp types
- Contact Rating: Up to #20 AWG stranded wire, 8 pounds contact retention force
- Environmental Sealing: Effective from full to nearly full engagement
- Altitude Range: operation up to 70,000 feet
- Insulation Resistance: Greater than 5,000 megohms
- Vibration Resistance: Exceeds MIL-STD-202A, Method 204, Condition D
- Corrosion Resistance: Exceeds 50-hour salt spray MIL-STD-202A, Method 101A
- Moisture Resistance: Exceeds MIL-STD-202A, Method 106
- Shock Resistance: Exceeds MIL-STD-202A, Method 213, Condition G
- Voltage Rating: AC rms, 60Hz, at 25°C, values not specified but compliant
- Dimensions: Varies by shell size, detailed in technical drawings
- Temperature Rating: Not explicitly specified, suitable for aerospace environments
Buy the Buy Interconnect Solutions Environmental Series Connector Part Number M2430815F Online
Order the Interconnect Solutions environmental connector online today and ensure reliable performance in aerospace, military, and ground support applications. Designed with a rugged aluminum shell and corrosion-resistant gold-plated contacts, this high-altitude capable connector offers exceptional vibration and moisture resistance. Its versatile solder and crimp contact options accommodate various wire sizes, supporting demanding environmental conditions up to 70,000 feet altitude. Easy to install with detailed dimensions, ensuring secure and durable connections for aerospace and ground systems.
Buy Interconnect Solutions M2430815F now and experience unmatched durability and performance in extreme aerospace conditions.
Frequently Asked Questions
Where can I buy AMPHENOL PCD M2430815F?
You can click on the BUY or RFQ button to purchase M2430815F from an authorized AMPHENOL PCD distributor.
How do I troubleshoot issues or seek technical support for part M2430815F?
You can download the M2430815F datasheet or visit the AMPHENOL PCD website for support.
Who is the manufacturer of M2430815F?
AMPHENOL PCD
