AMPHENOL PCD USBFTV6G Rugged USB Connection System
The USBFTV6G is a rugged and reliable USB connection system designed for harsh environments, featuring a durable olive drab cadmium-plated aluminum shell. It supports standard USB 2.0 cordsets, providing data transfer rates up to 480 Mb/s. Engineered with MIL-DTL-38999 series III tri-start thread coupling and anti-decoupling features, it offers IP68 sealing against dust and fluids. This connector ensures high shock, vibration, and tension resistance, making it ideal for military, aerospace, and industrial applications requiring secure, waterproof connections without tools or field cabling. The system assures plug retention of 100N in the axis and endures over 500 mating cycles.
AMPHENOL PCD USBFTV6G Rugged USB Connection System Specifications:
- Shell Material: Aluminum, Olive Drab Cadmium-Plated
- Sealing: IP68, waterproof and dustproof
- Data Rate: Up to 480 Mbps (USB 2.0)
- Vibration Resistance: 10-500 Hz, 10 g, 3 axes
- Shock Resistance: 250 g drop from 40 cm
- Plug Retention Force: 100 N axial
- Mating Cycles: 500 to 1500
- Temperature Range: -40°C to +85°C
- Corrosion Resistance: Nickel plated for salt spray 48h, Olive Drab Cadmium for 500h, Marine bronze shell for 1000h
- Type: Square flange receptacle with optional panel drilling and backshells
- Application: Military, aerospace, industrial, data acquisition, harsh environments
Buy the Amphenol Series USB Field TV: USBFTV6G
Enhance your projects with the reliable Amphenol Series USBFTV6G rugged USB connection system, offering waterproof IP68 sealing, high vibration and shock resistance, and corrosion-proof materials. Designed for demanding military, aerospace, and industrial environments, this system allows secure, tool-free connections with plug retention force of 100N. Compatible with standard USB 2.0 cordsets, it delivers data rates up to 480 Mbps. With options for square flange receptacles and various backshells, it ensures durable performance in extreme conditions. Buy online now for quick, dependable installation.
Order your Amphenol Series USBFTV6G rugged USB connection today and ensure reliable, sealed data transfer in the toughest environments.
Frequently Asked Questions
Where can I buy AMPHENOL PCD USBFTV6G?
You can click on the BUY or RFQ button to purchase USBFTV6G from an authorized AMPHENOL PCD distributor.
How do I troubleshoot issues or seek technical support for part USBFTV6G?
You can download the USBFTV6G datasheet or visit the AMPHENOL PCD website for support.
Who is the manufacturer of USBFTV6G?
AMPHENOL PCD
