FERRAZ SHAWMUT A100P1004TA High Speed Fuse
The FERRAZ SHAWMUT A100P100-4TA is a high-speed fuse rated for 1000V, providing reliable protection for a wide range of applications including UPS systems, AC and DC drives, and reduced voltage motor starters. Its fast-acting and current-limiting features minimize damage to protected components, while the controlled arc voltage reduces stress on circuit components during fuse clearing. Available in a variety of ampere ratings, this fuse offers a versatile solution for high-voltage applications.
FERRAZ SHAWMUT A100P1004TA High Speed Fuse Specifications:
- Volts: 1000VAC, 750VDC
- Amps: 15 to 1000A
- I.R.: 100kA
- LR: 25ms
- Fast Acting: Yes
- Current Limiting: Yes
- Low I[2] t: Yes
- Applications: UPS systems, AC/DC drives, reduced voltage motor starters
- UL Recognized Component: File E60314
- AC UL Guide No.: JFHR2 (35-600A)
- DC Self-Certified: Yes
- Mounting Types: Bolt-in
- Fuse Catalog Ampere Rating: 35-1000A
