IQD FREQUENCY PRODUCTS LFSPXO025166 Crystal Oscillator
The LFSPXO025166 is a standard 3.2 x 2.5 mm ceramic crystal oscillator with a hermetically sealed metal lid, designed for high stability and reliable performance. Operating at 48.0 MHz, it features a frequency tolerance and stability suitable for precise timing applications. The device is powered by 3.3V with a maximum current draw of 20mA and offers CMOS output compatibility with a load capacity of 15pF. Its robust construction ensures resistance to shock and vibration, making it ideal for industrial and embedded systems requiring dependable oscillators.
IQD FREQUENCY PRODUCTS LFSPXO025166 Crystal Oscillator Specifications:
- Frequency: 48.0 MHz
- Frequency Tolerance @ 25°C: Inclusive
- Frequency Stability: +50.00ppm
- Operating Temperature Range: -40.00 to 85.00°C
- Supply Voltage: 3.3V
- Supply Voltage Tolerance: +10%
- Current Draw: 20mA max
- Output Compatibility: CMOS
- Output Load: 15pF max
- Rise and Fall Time: Sns max
- Duty Cycle: 45/55%
- Standby Operation: Logic '1' enables output, Logic '0' disables with high impedance
- Standby Current: 10A max
- Start-Up Time: 10ms max
- Shock Resistance: 1000G, MIL-STD-202F, Method 213B
- Vibration Resistance: 20G, MIL-STD-202F, Method 204D
- Storage Temperature Range: -55 to 125°C
- Package Type: Reel Tape and reel in accordance with EIA-481-D
- Pack Size: 1,000
- Outline Dimensions: Max 3.4 mm
- Waveform: 50% Vs, 10% Vs
Buy the IQD Frequency 025166 – Reliable Crystal Oscillator for Industrial Applications
Discover the high-quality 48.0 MHz crystal oscillator designed for industrial and critical timing applications. Featuring a hermetically sealed ceramic package, it offers excellent stability, low jitter, and robust resistance to shock and vibration. Powered by 3.3V with a low 20mA current draw, this oscillator provides CMOS output compatibility and supports loads up to 15pF. Ideal for use in communication, automation, and embedded systems, it ensures reliable performance under demanding environmental conditions, delivering consistent, accurate timing essential for precision devices.
Buy IQD frequency 025166 now and experience unmatched reliability and performance in precise timing solutions.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFSPXO025166?
You can click on the BUY or RFQ button to purchase LFSPXO025166 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFSPXO025166?
You can download the LFSPXO025166 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFSPXO025166?
IQD FREQUENCY PRODUCTS
