IQD FREQUENCY PRODUCTS LFSPXO027533 Crystal Oscillator
This is a standard 3.2 x 2.5mm hermetically sealed ceramic crystal oscillator with a metal lid, designed for precise timing applications. Operating from 50.0MHz, it features a frequency stability of +£100.00ppm over -40°C to 85°C, with aging of +3ppm/year at 25°C. It consumes 20mA at 3.3V, with CMOS output, 15pF maximum load, and rise/fall times below 5ns. The device supports standby operation, start-up times under 10ms, and complies with RoHS and REACh standards. Suitable for embedded systems, communication equipment, and industrial electronics.
IQD FREQUENCY PRODUCTS LFSPXO027533 Crystal Oscillator Specifications:
- Frequency: 50.0MHz
- Frequency Stability: +£100.00ppm
- Temperature Range: -40°C to 85°C
- Aging: +3ppm max per year at 25°C
- Supply Voltage: 3.3V ±10%
- Current Draw: 20.00mA
- Output Compatibility: CMOS
- Load Capacitance: 15pF max
- Rise and Fall Time: 5.0ns max
- Duty Cycle: 45/55%
- Standby Current: 10A max
- Start-Up Time: 10ms max
- Storage Temperature: -55°C to 125°C
- Shock Resistance: 1000G (MIL-STD-202F, Method 213B)
- Vibration: 20G (MIL-STD-202F, Method 204D)
- Packaging: Reel with 1,000 units, compliant with IEC-481-D
- Outline Dimensions: 3.2 x 2.5mm
- Sealed ceramic package with metal lid
Buy the Elite Series Crystal Oscillator: LFSPX0027533
Order the Elite Series LFSPX0027533 crystal oscillator today to ensure high stability and reliable performance in your electronic projects. Its hermetically sealed ceramic package provides exceptional environmental resistance, making it ideal for industrial, communication, and embedded systems. With a frequency of 50MHz, low power consumption, and fast startup time under 10ms, this oscillator guarantees precise timing. Available in reel packaging, it supports easy integration into manufacturing processes. Invest in quality and enhance your device’s performance with this trusted crystal oscillator.
Buy Elite Series LFSPX0027533 crystal oscillator now and experience unmatched reliability and performance in precision timing applications.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFSPXO027533?
You can click on the BUY or RFQ button to purchase LFSPXO027533 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFSPXO027533?
You can download the LFSPXO027533 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFSPXO027533?
IQD FREQUENCY PRODUCTS
