IQD FREQUENCY PRODUCTS LFSPXO053125 Crystal Oscillator
This surface mount crystal oscillator measures 3.2 x 2.5mm, sealed in a hermetic ceramic package with a metal lid. Operating at 32.0MHz, it offers a frequency stability of +25.00ppm across a temperature range of -40°C to 85°C. The device consumes 20mA at 3.3V, with a start-up time of 10ms. It supports CMOS output, with a drive capability of 15pF max, and features standby operation, with standby current up to 10A. Ruggedly designed to withstand shock and vibration per MIL standards, it is RoHS compliant and packaged in tape, cut from reels for easy mounting.
IQD FREQUENCY PRODUCTS LFSPXO053125 Crystal Oscillator Specifications:
- Frequency: 32.0MHz
- Frequency Stability: +25.00ppm
- Operating Temperature Range: -40°C to 85°C
- Start-Up Time: 10ms max
- Supply Voltage: 3.3V ±10%
- Current Draw: 20mA
- Output Voltage: CMOS compatible, 15pF max load
- Rise and Fall Time: 5.0ns max
- Duty Cycle: 45/55%
- Standby Current: 10A max
- Shock Resistance: 1000G, 0.5ms, MIL-STD-202F, Method 213B
- Vibration Resistance: 20g, 10Hz-2000Hz, MIL-STD-202F, Method 204D
- Storage Temperature Range: -55°C to 125°C
- RoHS and REACh compliant, Packaged in tape, cut from reel
- Outline Dimensions: 3.240mm x 2.000mm
- Soldering Temperature: Max 260°C for 10 seconds
Buy the Crystal Oscillator Series LFSPXO Series: 32.0MHz Oscillator Part LFSPXO053125
Order the Crystal Oscillator LFSPXO053125 online today for reliable high-frequency performance in demanding environments. Its compact hermetic ceramic package ensures durability, stability, and precision from -40°C to 85°C. With features like low jitter, CMOS output, fast start-up time, and excellent shock and vibration resistance, this oscillator is perfect for industrial, communications, and timing applications. Secure your supply today and benefit from quick delivery, quality assurance, and competitive pricing.
Buy Crystal Oscillator LFSPXO053125 now and experience unmatched reliability and performance in compact hermetic packages, ideal for high-precision timing applications.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFSPXO053125?
You can click on the BUY or RFQ button to purchase LFSPXO053125 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFSPXO053125?
You can download the LFSPXO053125 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFSPXO053125?
IQD FREQUENCY PRODUCTS
