IQD FREQUENCY PRODUCTS LFSPXO064158 Ceramic Oscillator
This ceramic packaged oscillator provides a stable 32.0MHz frequency with ±25ppm stability, suitable for precise timing applications. It operates from -20°C to 70°C, with excellent ageing performance of +3ppm per year at 25°C. The device features low power consumption with a 3.3V supply, 20mA current draw, and enables/disables output functionality via logic control. It is RoHS compliant, shock and vibration resistant, and ideal for embedded systems, communication equipment, and industrial electronics requiring reliable clock signals with minimal jitter and fast start-up times.
IQD FREQUENCY PRODUCTS LFSPXO064158 Ceramic Oscillator Specifications:
- Frequency: 32.0MHz
- Frequency Stability: ±25.00ppm
- Operating Temperature Range: -20.00 to 70.00°C
- Ageing: +3ppm max per year @ 25°C
- Supply Voltage: 3.3V ±10%
- Current Draw: 20.000mA
- Output Type: HCMOS
- Output Capacitance: 15pF
- Rise and Fall Time: 7.0ns max
- Duty Cycle: 40/60%
- Start Up Time: 10ms max
- Output Low Voltage: 10%Vs max
- Output High Voltage: 90%Vs min
- Stand-by Current: 10uA max, 1.0uA typ @ 25°C
- Period Jitter: ±80ps pk-pk
- Phase Jitter: 1ps rms between 12kHz and 20MHz
- Storage Temperature Range: -55 to 125°C
- Shock Resistance: MIL-STD-883 Method 2002 Condition B
- Vibration Resistance: MIL-STD-883 Method 2007 Condition A
- RoHS Compliant, REACh Status: Compliant
- Reflow Temp: 260°C max for 10 seconds
- Packaging: Cutt tape, pack size 100
Buy the Generic LFSPXO064158 Reliable Ceramic Oscillator for Industrial Applications
Purchase the ceramic oscillator with 32MHz frequency, ±25ppm stability, low power consumption, RoHS compliance, and excellent reliability. This oscillator is ideal for industrial electronic systems, embedded devices, and communication equipment needing precise timing signals. It features a fast start-up time of 10ms, low jitter, and robust shock and vibration resistance. Easy to integrate with enable/disable control, making it suitable for demanding environments. Order online now for quality performance with proven durability and stability in critical industrial applications.
Get Generic LFSPXO064158 today—built for precision and long-lasting durability in industrial and electronic timing systems.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFSPXO064158?
You can click on the BUY or RFQ button to purchase LFSPXO064158 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFSPXO064158?
You can download the LFSPXO064158 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFSPXO064158?
IQD FREQUENCY PRODUCTS
