IQD FREQUENCY PRODUCTS LFSPXO076706 Crystal Oscillator
The crystal oscillator is a surface-mount device measuring 3.2 x 2.5mm, housed in a hermetically sealed ceramic package with a metal lid. Operating at 80.0MHz, it features ±25ppm stability, with a temperature range from -40°C to 85°C and aging of +3ppm per year at 25°C. Powered by 3.3V with a maximum current of 30mA, it provides CMOS output with 15pF load, rise/fall time of 5.0ns, and a duty cycle of 40/60%. It supports standby operation, with a low current of 10A, and withstands shock and vibration per MIL-STD standards. RoHS and REACh compliant, packaged in cut tape, and capable of withstanding a reflow temperature of 260°C for 10s.
IQD FREQUENCY PRODUCTS LFSPXO076706 Crystal Oscillator Specifications:
- Frequency: 80.0MHz
- Frequency Stability: +25.00ppm
- Operating Temperature Range: -40°C to 85°C
- Aging: +3ppm/year at 25°C
- Supply Voltage: 3.3V ±10%
- Current Draw: 30mA
- Output Type: CMOS
- Output Load: 15pF max
- Rise and Fall Time: 5.0ns max
- Duty Cycle: 40/60%
- Start-Up Time: 10ms max
- Standby Current: 10A max
- Storage Temperature Range: -55°C to 125°C
- Shock Resistance: 1000G, 0.5ms MIL-STD-202F Method 213B
- Vibration Resistance: 20g, 10Hz-2000Hz, 12hrs total MIL-STD-202F Method 204D
- Termination: RoHS compliant NiAu
- Reflow Temperature: 260°C max for 10s
- Packaging: Cut tape, pack size 100
- Outline Dimensions: 3.2 x 2.5mm
- Pad Connections: 4
- Standby Operation: Logic ‘1’ enables, Logic ‘0’ disables output, high impedance when disabled
Buy the IQD Frequency Products LFSPXO076706 U– Reliable Crystal Oscillator for Industrial Applications
Purchase the crystal oscillator online to ensure reliable timing signals in your industrial applications. Featuring 80MHz frequency, ±25ppm stability, low power consumption of 30mA, and operating temperature range from -40°C to 85°C, this surface-mount device is housed in a hermetically sealed ceramic package. It offers CMOS output with 15pF load, rise/fall time of 5ns, and a duty cycle of 40/60%. RoHS compliant, packaged in cut tape for easy handling, and capable of withstanding shock and vibration. Order now for high precision and durability.
Get IQD Frequency Products LFSPXO076706 today—built for precision, low power, and long-lasting durability in industrial electronics.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFSPXO076706?
You can click on the BUY or RFQ button to purchase LFSPXO076706 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFSPXO076706?
You can download the LFSPXO076706 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFSPXO076706?
IQD FREQUENCY PRODUCTS
