IQD FREQUENCY PRODUCTS LFSPXO076709 High-Performance Crystal Oscillator
This surface mount crystal oscillator measures 3.2 by 2.5mm in a hermetically sealed ceramic package with a metal lid, designed for high precision timing applications. Operating over -40°C to 85°C, it offers a frequency stability of ±25ppm at 125MHz and includes features like CMOS output, 15pF drive capability, and a 10ms start-up time. Its environmental resilience includes shock and vibration tolerance, making it suitable for robust industrial and communication systems demanding reliable high-frequency oscillators.
IQD FREQUENCY PRODUCTS LFSPXO076709 High-Performance Crystal Oscillator Specifications:
- Frequency: 125.0MHz
- Frequency Stability: +25.00ppm
- Operating Temperature Range: -40°C to 85°C
- Supply Voltage: 3.3V ±10%
- Current Draw: 30.000mA
- Output Compatibility: CMOS
- Drive Capability: 15pF max
- Rise and Fall Time: 5.0ns max
- Duty Cycle: 40/60%
- Start-Up Time: 10ms max
- Standby Current: 10A max
- Storage Temperature Range: -55°C to 125°C
- Shock Resistance: 1000G, MIL-STD-202F, Method 213B
- Vibration Resistance: 20g, MIL-STD-202F, Method 204D, Test Condition D
- Packaging: Reel, 1000 units per reel
- RoHS compliant, MSL rating: JDEC-STD-033
- Maximum Soldering Temperature: 260°C for 10 seconds
Buy the Crystal Oscillator 125MHz – Reliable Timing for Industrial Applications
Enhance your electronic designs with this high-precision crystal oscillator capable of operating at 125MHz with ±25ppm stability. It features a hermetically sealed ceramic package, CMOS output, and robust environmental resistance, making it ideal for industrial, communication, and measurement systems. Its reliable start-up time, low power consumption, and compatibility with standard drive loads ensure optimal performance. Purchase this crystal oscillator online to secure a stable, resilient timing source for your critical projects and ensure long-term reliability for demanding applications.
Get Crystal Oscillator 125MHz today—built for precision, stability, and long-lasting durability in demanding industrial environments.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFSPXO076709?
You can click on the BUY or RFQ button to purchase LFSPXO076709 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFSPXO076709?
You can download the LFSPXO076709 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFSPXO076709?
IQD FREQUENCY PRODUCTS
