IQD FREQUENCY PRODUCTS LFSPXO082199 Crystal Oscillator
The LFSPX0082199C is a precise crystal clock oscillator in a ceramic package with a hermetically sealed metal lid, operating at 4.0MHz. It offers high stability with a frequency stability of +25.00ppm and operates within -20.00 to 70.00°C. Designed for reliable performance, it features low power consumption with a supply voltage of 3.3V and a standby current of 10uA. Its output is HCMOS compatible with fast rise and fall times, making it ideal for timing and synchronization in electronic systems.
IQD FREQUENCY PRODUCTS LFSPXO082199 Crystal Oscillator Specifications:
- Frequency: 4.0 MHz
- Frequency Stability: +25.00ppm
- Operating Temperature Range: -20.00 to 70.00°C
- Aging: +3ppm max per year at 25°C
- Supply Voltage: 3.3V ±10%
- Current Draw: 7.000mA
- Output Type: HCMOS
- Output Capacitance: 15pF
- Rise and Fall Time: 7.0ns max
- Duty Cycle: 40/60%
- Start Up Time: 1QX0-791 is approx. 0.7ms
- Output Low Voltage: 10%Vs max
- Output High Voltage: 90%Vs min
- Stand-by Current: 10uA max
- Jitter: Period pk-pk 80ps typ, phase rms 1ps
- Storage Temperature Range: -55 to 125°C
- Mechanical Shock: MIL-STD-883, Method 2002, Condition B
- Vibration: MIL-STD-883, Method 2007, Condition A
- RoHS compliant: Yes
- Reflow Temp: 260°C max for 10 seconds
- Package Style: Cut tape, 100 units per pack
Buy the IQD Series Oscillator: 4MHz Crystal Clock: LFSPXO082199
Purchase the IQD LFSPX0082199C crystal oscillator online now to ensure precise timing in your electronic projects. Designed with a hermetic ceramic package, it provides high stability, low power consumption, and fast start-up time. Ideal for timing circuits, communication equipment, and industrial control systems, this oscillator complies with RoHS standards for environmental safety. Easily integrate with your system thanks to its standard CMOS output, 15pF capacitance, and robust operation over wide temperature ranges, ensuring reliable performance in demanding conditions.
Get IQD LFSPX0082199C today—built for precision and long-lasting durability in electronic timing applications.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFSPXO082199?
You can click on the BUY or RFQ button to purchase LFSPXO082199 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFSPXO082199?
You can download the LFSPXO082199 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFSPXO082199?
IQD FREQUENCY PRODUCTS
