IQD FREQUENCY PRODUCTS LFSPXO082201 Crystal Oscillator
The LFSPX0082201C is a standard 12.288 MHz crystal oscillator housed in a hermetically sealed ceramic package with a metal lid. Designed for precision timing applications, it offers stability of +25 ppm, operating temperature range from -20°C to 70°C, and aging of +3 ppm annually at 25°C. It features low power consumption with a supply voltage of 3.3V, current draw of 7.000mA, and output drive capability suitable for high-speed digital circuits. The oscillator supports enabling/disabling control, with a start-up time of 10ms, and adheres to RoHS standards. Connectors include output impedance with rise and fall times under 7ns, making it ideal for timing and synchronization in electronic systems.
IQD FREQUENCY PRODUCTS LFSPXO082201 Crystal Oscillator Specifications:
- Frequency: 12.2880 MHz
- Frequency Stability: +25.00 ppm
- Operating Temperature Range: -20.00 to 70.00°C
- Aging: +3 ppm max per year @ 25°C
- Supply Voltage: 3.3V ±10%
- Current Draw: 7.000mA
- Output Compatibility: HCMOS
- Output Voltage Levels: VoL: 10% Vs max, VoH: 90% Vs min
- Rise and Fall Time: 7.0ns max
- Start Up Time: 10ms max
- Output Drive Capability: Suitable for digital circuits
- Output Control: Enable/Disable with logic '1' and '0' control
- Stand-by Current: 10μA max @ 25°C
- Noise Parameters: Period jitter pk-pk: +80ps typ, Phase jitter rms: 1ps
- Storage Temperature Range: -55 to 125°C
- Mechanical Shock: MIL-STD-883, Method 2002, Condition B
- Vibration: MIL-STD-883, Method 2007, Condition A
- RoHS and REACh compliant
- Reflow Temperature: 260°C max for 10 seconds
- Package: Ceramic with hermetic metal lid, 2540.1 mm outline
- Pack Style: Cutt tape, 100 pcs per pack
Buy the Buy IQD Crystal Oscillator Part Number LFSPX082201 Online
Enhance your electronic projects with the high-precision IQD crystal oscillator LFSPX082201, offering excellent frequency stability and low jitter. This oscillator is housed in a hermetically sealed ceramic package with a metal lid, ensuring reliable operation over wide temperature ranges from -20°C to 70°C. It consumes minimal power, with a supply voltage of 3.3V and a current draw of 7mA, making it suitable for demanding timing, synchronization, and communication applications. Its RoHS compliance and robust build ensure long-lasting performance in critical electronic systems.
Order your IQD Series LFSPX082201 oscillator today and ensure your timing circuits have the high stability and low jitter performance needed.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFSPXO082201?
You can click on the BUY or RFQ button to purchase LFSPXO082201 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFSPXO082201?
You can download the LFSPXO082201 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFSPXO082201?
IQD FREQUENCY PRODUCTS
