IQD FREQUENCY PRODUCTS LFSPXO082202 Surface Mount Oscillator
The oscillator is a standard 2.5 x 2.0 mm ceramic package device offering a 16.0 MHz frequency with exceptional stability of ±25 ppm over the operating temperature range of -20°C to 70°C. It features CMOS output levels, low supply current of 7 mA at 3.3V, and a start-up time of 10ms. Designed for high reliability, it complies with RoHS standards, and is ideal for precise timing applications requiring low jitter, excellent temperature stability, and robust environmental resistance in compact electronics.
IQD FREQUENCY PRODUCTS LFSPXO082202 Surface Mount Oscillator Specifications:
- Frequency: 16.0 MHz
- Frequency Stability: ±25.00 ppm
- Operating Temperature Range: -20°C to 70°C
- Storage Temperature Range: -55°C to 125°C
- Supply Voltage: 3.3V ±10%
- Current Draw: 7.000mA
- Start Up Time: 10ms max
- Output Voltage Levels: High ≥ 90%Vs, Low ≤ 10%Vs
- Output Drive Capability: CMOS
- Output Control: Enable/Disable logic high impedance when disabled
- Rise and Fall Time: 7.0ns max
- Duty Cycle: 40/60%
- Period Jitter: ±80ps pk-pk
- Vibration: MIL-STD-883, Method 2007, Condition A
- Shock: MIL-STD-883, Method 2002, Condition B
- RoHS and REACh compliant
- Packaging: Cutt tape, 100 pieces per pack
- Reflow Temp: Max 260°C for 10 seconds
Buy the Electronics Series Oscillator: LFSPX082202
Purchase the IQD LFSPX082202 oscillator online today to ensure your electronic devices benefit from precise frequency stability, low jitter, and excellent environmental resistance. This compact 16 MHz ceramic oscillator is perfect for space-constrained applications requiring high reliability, low phase jitter, and robust operation in varying temperatures. With RoHS compliance and a quick start-up time, it provides dependable performance for telecommunications, instrumentation, and embedded systems. Order now for fast delivery and optimal device performance.
Buy IQD Frequency Products LFSPX082202 oscillator now and experience unmatched reliability and high precision timing for your electronic projects.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFSPXO082202?
You can click on the BUY or RFQ button to purchase LFSPXO082202 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFSPXO082202?
You can download the LFSPXO082202 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFSPXO082202?
IQD FREQUENCY PRODUCTS
