IQD FREQUENCY PRODUCTS LFSPXO082224 High-Precision Oscillator
This high-precision ceramic package oscillator operates at 26.0MHz with excellent stability of +25.00ppm, suitable for timing applications. It features a hermetically sealed metal lid, low power consumption of 10mA at 1.8V, and HCMOS output compatible with low rise and fall times of 10ns. Designed for operating temperatures from -20°C to 70°C and storage temperatures from -55°C to 125°C, it complies with RoHS and REACh standards. The device includes standby control, jitter performance, and withstands shock and vibration according to MIL standards, ensuring reliability.
IQD FREQUENCY PRODUCTS LFSPXO082224 High-Precision Oscillator Specifications:
- Frequency: 26.0MHz
- Frequency Stability: +25.00ppm
- Operating Temperature Range: -20°C to 70°C
- Storage Temperature Range: -55°C to 125°C
- Supply Voltage: 1.8V ±5%
- Current Draw: 10mA
- Output Compatibility: HCMOS
- Drive Capability: 15pF
- Rise and Fall Time: 10.0ns max
- Duty Cycle: 40/60%
- Output Voltage High: 90% of VS min
- Output Voltage Low: 10% of VS max
- Start Up Time: 10ms max, 0.9ms typical
- Jitter (pk-pk): +80ps typ
- Jitter (Phase 12kHz–20MHz): 1ps max
- Jitter (One Sigma): +10ps typ
- Shock Resistance: MIL-STD-202, Method 213
- Vibration Resistance: MIL-STD-883, Method 2007
- Compliance: RoHS 2011/65/EU, REACh
- Packaging: Tape, cut from reel, Part No. LFSPX0082224Cutt
- Dimensions and outline as per datasheet specifications
Buy the Buy IQD Frequency Products Oscillator Part Number LFSPXO082224 Online
Order the IQD Frequency Products high-precision oscillator LFSPXO082224 online today for reliable, low-noise performance. This 26MHz ceramic timing device features hermetic sealing, a stable frequency of +25ppm, and low power consumption of only 10mA at 1.8V. It ensures precise operation over a temperature range of -20°C to 70°C and withstands shock and vibration for demanding environments. Perfect for timing circuits, telecom, and industrial applications, this oscillator offers excellent jitter, quick start-up, and RoHS compliance—order now to secure your supply of a trusted and durable timing component.
Get IQD Frequency Products LFSPXO082224 today—built for precision and long-lasting durability in critical timing applications.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFSPXO082224?
You can click on the BUY or RFQ button to purchase LFSPXO082224 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFSPXO082224?
You can download the LFSPXO082224 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFSPXO082224?
IQD FREQUENCY PRODUCTS
