IQD-Frequency-Products LFXTAL003325 Crystal Oscillator
The LFXTAL003325 is a crystal oscillator featuring an industry-standard leaded package, resistance welded and hermetically sealed in an inert atmosphere with glass-to-metal seals on leads. It has a 2-leg design, operates at 24.0MHz with a frequency tolerance of +30.00ppm, and offers stable performance across temperatures from -10°C to 60°C. The device exhibits low load capacitance of 30.00pF, low ESR of 400 max, and is compliant with RoHS and REACh standards. Suitable for precise timing and frequency applications, it includes shock and vibration resistance for rugged environments.
IQD-Frequency-Products LFXTAL003325 Crystal Oscillator Specifications:
- Frequency: 24.0MHz
- Frequency Tolerance: +30.00ppm @ 25°C
- Frequency Stability: +5ppm typical per year at 25°C
- Operating Temperature Range: -10°C to 60°C
- Ageing: +5ppm per year
- Load Capacitance (Ct): 30.00pF
- Shunt Capacitance (Co): 7pF max
- Drive Level: 500uW max
- ESR: 400 max
- Shock Resistance: 981m/s², 6ms, 3 times in each of 3 mutually perpendicular planes
- Vibration Resistance: 10Hz-60Hz, 0.75mm amplitude, 98.1m/s² in 3 planes
- Storage Temperature Range: -55°C to 125°C
- Packaging: Bulk, 100 units per pack, loose in bulk pack
- Compliance: RoHS and REACh compliant
Buy the IQD Frequency Products Series Crystal Oscillator: LFXTAL003325
Purchase the IQD Frequency Products LFXTAL003325 crystal oscillator online today and ensure your electronic devices maintain accurate timing with excellent stability. Designed with industry-standard hermetically sealed packaging, this crystal provides low load capacitance, low ESR, and high resistance to shock and vibration. Ideal for applications demanding precise frequency control, it complies with RoHS and REACh standards, offering reliable performance across a wide temperature range. Simplify your procurement process and achieve superior device performance with this high-quality crystal oscillator, available for quick online ordering.
Buy IQD Frequency Products LFXTAL003325 crystal oscillator now and experience unmatched reliability and precise frequency stability for your electronic applications.
Frequently Asked Questions
Where can I buy IQD-Frequency-Products LFXTAL003325?
You can click on the BUY or RFQ button to purchase LFXTAL003325 from an authorized IQD-Frequency-Products distributor.
How do I troubleshoot issues or seek technical support for part LFXTAL003325?
You can download the LFXTAL003325 datasheet or visit the IQD-Frequency-Products website for support.
Who is the manufacturer of LFXTAL003325?
IQD-Frequency-Products
