IQD FREQUENCY PRODUCTS LFXTAL034655 Quartz Crystal

Name: LFXTAL034655 - Electronic Component
Brand: IQD FREQUENCY PRODUCTS
SKU: LFXTAL034655
Price: 0.367 USD
Availability: InStock
Rating: 5.0 (1 reviews)

This industry standard SMD quartz crystal features resistance welded, hermetically sealed construction in an inert atmosphere with glass-to-metal seals on leads. Designed with lead wires mounted onto a plastic former, it offers a gull-wing mount suitable for surface-mount applications. Operating at 16.0MHz with a frequency tolerance of +20.00ppm at 25°C, it provides excellent stability across -20°C to 70°C, fundamental overtone, and a low drive level of 500uW. It complies with RoHS and REACh, packaged in tape and reel, ideal for precise timing applications.

IQD Series HC4S Quartz Crystal: LFXTAL034655

View LFXTAL034655Datasheet [pdf]

IQD FREQUENCY PRODUCTS LFXTAL034655 Quartz Crystal Specifications:

Frequency: 16.0MHz
Tolerance: +20.00ppm at 25°C
Temperature Range: -20°C to 70°C
Overtone: Fundamental
Ageing: +5ppm per year at 25°C
Load Capacitance: 18.00pF
Shunt Capacitance: 7pF max
Drive Level: 500uW max
ESR: 40.000 max
Packaging: Reel, 1,000 units per reel
Package Height Options: HC4S/4HSMX 4.3mm max, HC49/3.5HSMX 3.7mm max, HC49/3HSMX 3.1mm max, HC49/2.5HSMX 2.85mm max
Shock Resistance: 981m/s², 6ms, 3 times in each plane
Vibration Resistance: 10Hz-60Hz, 0.75mm amplitude, 60Hz-500Hz, 98.1m/s² for 30 mins
Storage Temperature: -55°C to 125°C
Compliance: RoHS, REACh, MSL Level 1
Outline Dimension: 11.4+0.2mm
Solder Pad Layout: As specified in datasheet

Buy the IQD Series HC4S Quartz Crystal: LFXTAL034655

Purchase the IQD Series HC4S quartz crystal online today to benefit from high accuracy, robust hermetic sealing, and compliance with RoHS standards. Designed for surface-mount applications, its 16.0MHz frequency, low tolerance of +20.00ppm, and wide temperature range ensure excellent stability in various electronic timing circuits. Packaged in tape and reel, it supports automated assembly processes. Ideal for high-precision oscillators, communication equipment, and industrial control systems, this crystal guarantees reliable operation with low drive level and minimal aging for long-term performance stability.

Order your IQD Series HC4S quartz crystal today and ensure your timing circuits perform with maximum precision and reliability.
