IQD FREQUENCY PRODUCTS LFXTAL059461 Quartz Crystal
This 2.0 x 1.2mm SMD quartz crystal offers a hermetically sealed ceramic package with a metal lid, ideal for real-time clock applications. It operates at a frequency of 32.7680kHz with a tolerance of +20ppm, showcasing excellent stability from -40°C to 85°C. Designed with a fundamental overtone, it features low drive level, low motional capacitance, and high ESR. Compliant with RoHS and REACh standards, it's packaged in reels of 3,000, suitable for high-volume manufacturing and precision timing in electronics.
IQD FREQUENCY PRODUCTS LFXTAL059461 Quartz Crystal Specifications:
- Crystal Size: 2.0 x 1.2mm
- Frequency: 32.7680kHz
- Frequency Tolerance: +20ppm
- Temperature Range: -40°C to 85°C
- Drive Level: 0.1μW recommended
- Shunt Capacitance: 1.3pF typ, 1.7pF max
- Load Capacitance: 7.00pF
- ESR: 90kΩ max
- Aged: ±3ppm per year
- Vibration: IEC 60068-2-6, 1.5mm amplitude, 10-55Hz, 2hrs in each plane
- Shock: IEC 60068-2-27, 1000G, 1ms, three times in each of three planes
- Reflow Temperature: 260°C for seconds
- RoHS and REACh compliant
- Packaging: Reel of 3,000 units
Buy the ElaD Series Quartz Crystal: LFXTAL059461
Purchase the ElaD Series quartz crystal LFXTAL059461 online today and ensure your projects benefit from precise timing and exceptional stability. This 2mm x 1.2mm SMD crystal features hermetic sealing for durability and is suitable for high-volume manufacturing with reel packaging of 3,000 units. Its frequency of 32.768kHz with a tolerance of +20ppm guarantees reliable operation from -40°C to 85°C. RoHS and REACh compliant, it’s ideal for real-time clock applications in modern electronic devices, providing dependable performance for years.
Order your ElaD Series quartz crystal LFXTAL059461 today and enhance your electronic timing projects with reliable, proven stability.
