IQD-Frequency-Products LFXTAL060112 Quartz Crystal Oscillator
The HC49/3HSMX is a high-performance low-profile SMD quartz crystal oscillator valued for its hermetic sealing and glass-to-metal lead seals, ensuring reliability in demanding environments. Operating at 24.0MHz with a tolerance of ±30ppm, it features a fundamental overtone, temperature stability from -40°C to 85°C, and a low drive level of 500µW for efficient operation. Its compact outline, with models like HC49/4HSMX and HC49/2.5HSMX, makes it ideal for space-constrained designs in electronic and communication applications, providing stable and precise frequency signals.
IQD-Frequency-Products LFXTAL060112 Quartz Crystal Oscillator Specifications:
- Frequency: 24.0MHz
- Frequency Tolerance: ±30ppm @ 25°C
- Temperature Range: -40°C to 85°C
- Overtone: Fundamental
- Ageing: ±5ppm per year @ 25°C
- Load Capacitance: 18.00pF
- Shunt Capacitance: 7pF max
- Drive Level: 500µW max
- ESR: 40.000 max
- Sealing: Hermetically sealed glass-to-metal
- Form Factor: Surface Mount, low profile, various height options
- Packaging: Reel of 1,000 units, compliant with EIA-481-D
- Shock Resistance: 981m/s², 6ms, 3 times in each plane
- Vibration Resistance: 10Hz-60Hz, 0.75mm; 60Hz-500Hz, 98.1m/s²
- Storage Temperature: -55°C to 125°C
- RoHS Compliant, REACh Compliant, MSL Rating: Not Applicable
Buy the Buy IQD Frequency Products HC49/3HSMX Part Number LFXTAL060112 Online
Order the IQD Frequency HC49/3HSMX quartz crystal oscillator online today for reliable performance in embedded systems, communication equipment, and precision timing solutions. This low-profile, hermetically sealed device offers excellent temperature stability from -40°C to 85°C, a frequency of 24MHz, and tolerance of ±30ppm. Its rugged construction withstands shock and vibration, ensuring long-term stability. Ideal for space-constrained designs, it guarantees accurate frequency signals with minimal ageing, compliance with RoHS, and efficient reel packaging of 1,000 units for easy integration.
Get IQD Frequency Products HC49/3HSMX today—built for precise timing and long-lasting durability in electronic applications.
Frequently Asked Questions
Where can I buy IQD-Frequency-Products LFXTAL060112?
You can click on the BUY or RFQ button to purchase LFXTAL060112 from an authorized IQD-Frequency-Products distributor.
How do I troubleshoot issues or seek technical support for part LFXTAL060112?
You can download the LFXTAL060112 datasheet or visit the IQD-Frequency-Products website for support.
Who is the manufacturer of LFXTAL060112?
IQD-Frequency-Products
