IQD FREQUENCY PRODUCTS LFXTAL060213 Surface-Mount Crystal
This is a standard 5x3.2mm SMD crystal with four pads, housed in a hermetically sealed ceramic package with a seam-sealed metal lid. It features a frequency of 14.74560MHz, frequency tolerance of ±10.00ppm, and operates within -10°C to 60°C. Designed for reliable performance with shock resistance up to 1500G, vibration endurance, and RoHS compliance, it is ideal for precise timing applications. Suitable for surface-mount applications, this crystal ensures stability and accuracy in demanding environments, making it perfect for modern electronic circuits requiring high precision and stability.
IQD FREQUENCY PRODUCTS LFXTAL060213 Surface-Mount Crystal Specifications:
- Frequency: 14.74560MHz
- Frequency Tolerance: ±10.00ppm @ 25°C
- Frequency Stability: ±3ppm max per year @ 25°C
- Operating Temperature Range: -10°C to 60°C
- Storage Temperature Range: -55°C to 125°C
- Load Capacitance: 10.00pF
- Shunt Capacitance: 7pF max
- Drive Level: 1004W max
- ESR: 70.000 max
- Shock Resistance: 1500G, 0.5ms, 3 times
- Vibration: 20G, 20Hz-2000Hz, 1.52mm amplitude, 20 mins
- Package: Hermetically sealed ceramic with seam-sealed metal lid, reel packaging
- Pack Size: 1,000 units
- RoHS Status: Compliant
- REACH Status: Compliant
- MSL Rating: Not Applicable
- Material: Ceramic with metal lid sealing
- Dimensions: 5mm x 3.2mm
- Packaging: Tape and reel according to ElA-481-D
Buy the Buy IQD Frequency Products Crystal Part Number LFXTAL060213 Online
Purchase the IQD Frequency Products LFXTAL060213 crystal online to benefit from high precision, robust shock and vibration resistance, and RoHS compliance. This 14.74560MHz SMD crystal features a hermetically sealed ceramic package, ensuring excellent stability over a wide temperature range. Ideal for modern electronic devices requiring precise timing, this crystal provides reliable performance in rugged environments. Easily order via our secure online platform and get fast delivery, ensuring your project maintains accuracy and dependability with minimal effort.
Order your IQD Frequency Products LFXTAL060213 crystal today and ensure high stability and reliability for your precision timing needs.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFXTAL060213?
You can click on the BUY or RFQ button to purchase LFXTAL060213 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFXTAL060213?
You can download the LFXTAL060213 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFXTAL060213?
IQD FREQUENCY PRODUCTS
