IQD FREQUENCY PRODUCTS LFXTAL060250 Quartz Crystal
The LFXTAL060250 is a high-precision, hermetically sealed SMD quartz crystal in a compact 3.2 x 2.5mm ceramic package with a seam sealed metal lid. It operates at 26.0MHz with a frequency tolerance of +30.00ppm at 25°C and a stability of +30.00ppm across an operating temperature range of -20°C to 70°C. The crystal features a load capacitance of 10.00pF, shunt capacitance of 7pF max, drive level of 1004W max, and ESR up to 50Ω. Suitable for reliable use in various electronic and industrial applications, it complies with RoHS and REACh standards.
IQD FREQUENCY PRODUCTS LFXTAL060250 Quartz Crystal Specifications:
- Frequency: 26.0MHz
- Frequency Tolerance: +30.00ppm @25°C
- Frequency Stability: +30.00ppm
- Operating Temperature Range: -20°C to 70°C
- Ageing: +5ppm max per year @ 25°C
- Load Capacitance (CL): 10.00pF
- Shunt Capacitance (CO): 7pF max
- Drive Level: 1004W max
- ESR: 50Ω max
- Storage Temperature Range: -55°C to 125°C
- Shock Resistance: 1000G, 0.5ms MIL-STD-202F, Method 213B
- Vibration Resistance: 20G, 10Hz-2000Hz, 12hrs in three mutually perpendicular planes MIL-STD-202F, Method 204D
- Packaging: Reel, Pack Size: 1000 units, compliant with IEC-481-D
- Outline Dimensions: Max 3.4mm x 2.7mm
- Hermetically Sealed Ceramic Package with Seam Sealed Metal Lid
- RoHS and REACh Compliant
- MSL Rating: Not Applicable
Buy the IQD Frequency Products 26.0MHz U+2013 Reliable Quartz Crystal for Industrial Applications
Purchase the LFXTAL060250 quartz crystal online today for reliable, high-precision frequency stability in industrial and electronic applications. Its hermetically sealed ceramic package guarantees durability and consistent performance across a wide temperature range. This 26.0MHz crystal meets RoHS and REACh standards, ensuring compliance with global environmental regulations. With a compact size, low ESR, and excellent stability, it is ideal for use in oscillators, communication equipment, and precision timing devices. Order now to benefit from fast shipping and expert support for your electronic projects.
Buy IQD frequency crystals like the LFXTAL060250 now and experience unmatched reliability and precision for your industrial electronic projects.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFXTAL060250?
You can click on the BUY or RFQ button to purchase LFXTAL060250 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFXTAL060250?
You can download the LFXTAL060250 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFXTAL060250?
IQD FREQUENCY PRODUCTS
