IQD FREQUENCY PRODUCTS LFXTAL062558 Quartz Crystal
This is a 2.0 x 1.2mm SMD quartz crystal in a hermetically sealed ceramic package with an electron beam sealed metal lid. It operates at 32.7680 kHz, ideal for real-time clock applications. Featuring frequency tolerance of ±10 ppm at 25°C, it works across -40°C to 85°C and possesses aging of no more than 3 ppm per year. Designed with fundamental overtone, it offers stable performance with low ESR, and meets RoHS and REACH compliance standards, packaged in reels for easy surface-mount assembly.
IQD FREQUENCY PRODUCTS LFXTAL062558 Quartz Crystal Specifications:
- Frequency: 32.7680 kHz
- Frequency Tolerance: ±10 ppm at 25°C
- Operating Temperature Range: -40°C to 85°C
- Overtone: Fundamental
- Ageing: max 3 ppm per year at 25°C
- Motional Capacitance: 7 fF typical
- Load Capacitance: 9.00 pF
- Shunt Capacitance: 1.3 pF typ, 1.7 pF max
- Drive Level: 0.1 μW
- ESR: 70 kΩ max
- Maximum Reflow Temperature: 260°C
- Package: Hermetically sealed ceramic with metal lid
- Size: 2.0 x 1.2 mm
- Pack Style: Reel, Pack Size: 3,000 units
- Compliance: RoHS, REACH
- Shock Resistance: IEC 60068-2-27, 1000G, 1ms in 3 planes
- Vibration Resistance: IEC 60068-2-6, 1.5mm amplitude, 10Hz-55Hz, 2 hours per plane
Buy the IQD LFXTAL062558 – Reliable Quartz Crystal for Industrial Applications
Purchase the IQD SeriesLFXTAL062558 quartz crystal online now for accurate and reliable timing in your devices. This 32.768kHz fundamental crystal offers exceptional stability, low ESR, and excellent environmental resilience. Packaged in a hermetically sealed ceramic case, it is suitable for real-time clock modules, embedded systems, and industrial equipment. With RoHS and REACH compliance, it guarantees quality and environmental safety. Rapid online ordering ensures you receive this component quickly, supporting your production and development needs efficiently.
Order your IQD SeriesLFXTAL062558 quartz crystal today and ensure precise timing for your industrial clock and timing solutions.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFXTAL062558?
You can click on the BUY or RFQ button to purchase LFXTAL062558 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFXTAL062558?
You can download the LFXTAL062558 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFXTAL062558?
IQD FREQUENCY PRODUCTS
