IQD FREQUENCY PRODUCTS LFXTAL082080 Quartz Crystal
This quartz crystal is a 19.20MHz SMD component in a hermetically sealed ceramic package with a seam-sealed metal lid, designed for high stability and reliability in electronic circuits. It offers a frequency tolerance of ±10ppm at 25°C, frequency stability of ±10ppm, and a maximum aging rate of 3ppm per year. The crystal supports a load capacitance of 10pF, shunt capacitance of 5pF, and a drive level up to 1004W. It undergoes stringent environmental testing, including vibration and drop tests, and complies with RoHS and REACh standards. Suitable for use in precise timing and frequency control applications, it ensures long-term stability from -20°C to 70°C operating temperature.
IQD FREQUENCY PRODUCTS LFXTAL082080 Quartz Crystal Specifications:
- Frequency: 19.20MHz
- Frequency Tolerance: ±10ppm at 25°C
- Frequency Stability: ±10ppm
- Operating Temperature Range: -20 to 70°C
- Storage Temperature Range: -55 to 125°C
- Overtone: Fundamental
- Ageing: +3ppm max per year at 25°C
- Load Capacitance: 10pF
- Shunt Capacitance: 5pF max
- Drive Level: 1004W max
- ESR: 100Ω max
- Seam: Sealed metal lid
- Maximum Process Temperature: 260°C for 10 seconds
- Package Style: Cutt
- Pack Size: 100
- RoHS Compliant
- REACH Status: Compliant
- MSL Rating: Not Applicable
- Drop Test: 100cm onto hard wooden surface (3 times)
- Vibration: MIL-STD-883F, Method 2007.3: 20G, 20Hz-2000Hz, 1.52mm amplitude for 4 hours in three perpendicular planes
Buy the Buy IQD Frequency Crystal Part Number LFXTAL082080 Online
Experience reliable performance with the IQD quartz crystal, model LFXTAL082080, offering 19.20MHz frequency, ±10ppm tolerance, and excellent stability. This hermetically sealed SMD component is designed for high-precision timing in electronic devices, with stringent environmental testing including vibration and drop resistance. RoHS compliant and suitable for demanding industrial applications, it provides long-term durability in a compact 2.5 x 2mm package. Purchase online today for consistent, high-quality frequency control.
Buy IQD frequency crystal LFXTAL082080 now and ensure precise timing with excellent thermal stability and environmental resistance.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFXTAL082080?
You can click on the BUY or RFQ button to purchase LFXTAL082080 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFXTAL082080?
You can download the LFXTAL082080 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFXTAL082080?
IQD FREQUENCY PRODUCTS
