IQD FREQUENCY PRODUCTS LFXTAL082081 Quartz Crystal Oscillator
This 20.0 MHz SMD quartz crystal features a hermetically sealed ceramic package with a seam-sealed metal lid, ensuring durability and stability. It offers a frequency tolerance of ±10 ppm at 25°C, with a temperature stability from -20°C to 70°C and an ageing rate of +3 ppm annually. The device has low load capacitance of 10 pF, shunt capacitance of 5 pF, drive level of 100 μW, and ESR up to 100 Ω. It complies with RoHS standards and is suitable for precise timing applications in electronics.
IQD FREQUENCY PRODUCTS LFXTAL082081 Quartz Crystal Oscillator Specifications:
- Frequency: 20.0 MHz
- Frequency Tolerance: ±10 ppm @ 25°C
- Temperature Range: -20°C to 70°C
- Ageing: +3 ppm max per year
- Load Capacitance: 10 pF
- Shunt Capacitance: 5 pF
- Drive Level: 100 μW
- ESR: 100 Ω max
- Hermetically sealed ceramic package
- Seal: Seam sealed metal lid
- Package Size: 2.5 x 2 mm
- Outline: 2.54 mm pitch
- Storage Temperature Range: -55°C to 125°C
- Drop Test: 100cm onto hardwood up to 3 times
- Vibration: MIL-STD-883F, Method 2007.3, 20G, 20Hz-2000Hz
Buy the IQD Series Crystal Oscillator: LFXTAL082081
Enhance your electronic designs with the high-precision IQD Quartz Crystal Oscillator. Featuring a 20 MHz frequency, ±10 ppm tolerance, and robust hermetic sealing, this component guarantees stability and durability. Its low load capacitance, low ESR, and wide temperature range make it ideal for timing in telecommunications, industrial, and consumer electronics. Compliant with RoHS standards, this crystal provides reliable performance in demanding environments. Order online today to ensure your projects achieve accurate timing with proven, high-quality components.
Buy IQD LFXTAL082081 now and experience unmatched reliability and performance in precise frequency generation.
Frequently Asked Questions
Where can I buy IQD FREQUENCY PRODUCTS LFXTAL082081?
You can click on the BUY or RFQ button to purchase LFXTAL082081 from an authorized IQD FREQUENCY PRODUCTS distributor.
How do I troubleshoot issues or seek technical support for part LFXTAL082081?
You can download the LFXTAL082081 datasheet or visit the IQD FREQUENCY PRODUCTS website for support.
Who is the manufacturer of LFXTAL082081?
IQD FREQUENCY PRODUCTS
