MURATA POWER SOLUTIONS DMS20LCD420PC Datasheet & Stock
The DMS-20LCD-4/20P-C is a loop-powered, positive-reading LCD meter designed for process monitoring and measurement applications. It features a 3½-digit LCD display with a 4 to 20mA input, producing minimal voltage drop (approximately 1.8V to 2V), which results in a burden voltage of less than 100 ohms. This super-low voltage drop allows easy integration anywhere in the current loop via a simple two-wire connection. The device offers easy configuration with a 6-position DIP switch with gold-plated contacts for range and decimal point selection, eliminating the need for jumpers or soldered jump settings. Connection to the loop utilizes a secure screw-type terminal block. An optional bezel with a rubber seal provides robust panel mounting, suitable for dusty and moist environments. It operates self-powered, requiring no external power source, and is rated for temperatures from 0 to 60°C. Suitable for industrial, metering, testing, and measurement applications.
Frequently Asked Questions
Where can I buy MURATA POWER SOLUTIONS DMS20LCD420PC?
You can click on the BUY or RFQ button to purchase DMS20LCD420PC from an authorized MURATA POWER SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part DMS20LCD420PC?
You can download the DMS20LCD420PC datasheet or visit the MURATA POWER SOLUTIONS website for support.
Who is the manufacturer of DMS20LCD420PC?
MURATA POWER SOLUTIONS
