Schneider Electric XB5FVG4 Pilot Light
The pilot light is a durable, flush-mounted indicator device featuring a red LED with a plain lens, designed for industrial control panels. Operating at 110-120 V AC, it provides a steady signal and features a built-in LED bulb, IP66/IP67/IP69 protection, and a robust dark grey plastic bezel. Suitable for harsh environments, it includes screw clamp terminals, a fixation collar, and a round shape with mounting diameter of 1.20 inches. Its rated service life exceeds 100,000 hours, making it ideal for reliable status indication in automation systems.
Schneider Electric XB5FVG4 Pilot Light Specifications:
- Mounting diameter: 1.20 in (30.5 mm)
- Height: 1.65 in (42 mm), Width: 1.44 in (36.6 mm), Depth: 2.17 in (55 mm)
- Light source: Protected LED, Red, Integral bulb base
- Rated supply voltage: 110-120 V AC 50/60 Hz
- Current consumption: 14mA
- Service life: 100,000 hours at rated voltage and 25 °C
- Protection degree: IP66, IP67, IP69, NEMA 13, NEMA 4X
- Vibration resistance: 5 gn 12-500 Hz
- Shock resistance: 50 gn 18 ms
- Ambient temperature for storage & operation: 0-158 °F (-40-70 °C)
- Overvoltage category: Class II IEC
- Certifications: UL Listed, CSA
- Connectivity: Screw clamp terminals, IEC 60947-1 compliant
- Electromagnetic compatibility: IEC 61000-4-2/4-3/4-4, IEC 55011
- Environmental resistance: Resistance to high pressure washer (7,000,000 Pa at 55°C)
Buy the Schneider Electric Series XB5 Pilot Light: XB5FVG4
Order the Schneider Electric XB5FVG4 pilot light online today to ensure your automation systems operate with reliable status indication. Featuring IP69K protection, a robust red LED signal, and a built-in steady light, it is designed for demanding industrial applications. Its compact round shape with a 1.20-inch mounting diameter makes installation straightforward. With a rated service life of over 100,000 hours, this device offers long-term durability. Secure your control panels with this high-quality, UL and CSA certified pilot light—easy to purchase online now.
Get Schneider Electric XB5FVG4 today—built for precision, long-lasting durability, and reliable control signaling in industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric XB5FVG4?
You can click on the BUY or RFQ button to purchase XB5FVG4 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part XB5FVG4?
You can download the XB5FVG4 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of XB5FVG4?
Schneider Electric
