Schneider Electric XB5FVG5 Pilot light
The pilot light is a built-in-flush, round signaling device with a bright orange plain lens, designed for industrial control panels. It features a protected LED light source, integral LED bulb, and is rated for 110–120 V AC supply voltage. Made with dark grey plastic bezel and fixing collar, it has a mounting diameter of 30.5 mm, height of 42 mm, and maximum width of 36.6 mm. The device offers IP66, IP67, IP69, and NEMA 13, 4X protection, with a service life of 100,000 hours. It complies with UL, CSA, IEC, and other standards, resistant to vibration and shock, suitable for harsh environments, and has screw clamp terminals for reliable wiring.
Schneider Electric XB5FVG5 Pilot light Specifications:
- Shape of signaling unit: Round head
- Color: Orange lens with plain lens operator
- Light source: Protected LED, integral bulb
- Rated supply voltage: 110-120 V AC
- Mounting diameter: 30.5 mm
- Height: 42 mm
- Maximum width: 36.6 mm
- Depth: 55 mm
- Terminals: Screw clamp, 2x1.5 mm² with cable end / 2x2.5 mm² without cable end
- IP protection: IP66, IP67, IP69, IP69K
- NEMA: 13, 4X
- Vibration resistance: 5 gn, 12-500 Hz
- Shock resistance: 50 gn, 18 ms; 30 gn at 11 ms
- Resistance to pressure washer: 7,000,000 Pa at 55°C
- Service life: 100,000 hours
- Standards: UL listed, CSA certified, IEC/EN standards
- Operating temperature: 0 to 70 °C
- Environmental protection: IP66/IP67/IP69/IP69K
- Certification: UL, CSA
- Construction: Plastic bezel and fixing collar
- Environmental: Recyclable with low environmental impact
- Supply frequency: 50/60 Hz
Buy the Schneider Electric XB5FVG5 – Reliable Pilot Light for Industrial Applications
Purchase the Schneider Electric XB5FVG5 pilot light today through our online store to ensure efficient and dependable signaling in your industrial applications. Designed with durable plastic and high IP ratings, this LED indicator provides bright, reliable orange illumination. Its built-in-flush round design fits seamlessly into control panels. With a service life of 100,000 hours and compliance with international standards, this pilot light guarantees long-lasting operation in harsh environments. Order now and enhance your control systems with top-quality signaling components.
Buy Schneider Electric XB5FVG5 now and experience unmatched reliability and performance in industrial control panels.
