Schneider Electric XB5FVG6 Pilot Light
The pilot light is a flush-mounted signaling device with a blue lens, protected LED light source, and built-in integral LED. Designed for industrial use, it features a dark grey plastic bezel and fixing collar. With a mounting diameter of 30.5 mm, it supports 110-120 V AC supply voltage, and has a steady signaling type. Resistant to high-pressure washes, it complies with multiple safety standards, including IP66/IP67/IP69 protections and UL, CSA certifications. Suitable for control panels and automation systems, it offers long service life and reliable illumination for industrial signaling applications.
Schneider Electric XB5FVG6 Pilot Light Specifications:
- Mounting Diameter: 30.5 mm (1.20 in)
- Shape of Signaling Unit: Round
- Lens Color: Blue
- Light Source: Protected Built-in LED
- Rated Voltage: 110-120 V AC 50/60 Hz
- Power Consumption: 14 mA
- Height: 42 mm (1.65 in)
- Maximum Width: 36.6 mm (1.44 in)
- Depth: 55 mm (2.17 in)
- Terminal Type: Screw clamp, <= 2 x 1.5 mm² with cable end
- Insulation Voltage: 250 V (pollution degree 3)
- Impulse Withstand Voltage: 4 kV
- Protection Degree: IP66, IP67, IP69, NEMA 13, NEMA 4X
- Vibration Resistance: 5 gn 12-500 Hz
- Shock Resistance: 50 gn 18 ms
- Resistance to Fast Transients: 2 kV
- Electromagnetic Compatibility: IEC 61000-4-2/-4-3/-4-4, Class B emission
- Service Life: 100,000 hours at 25°C
- Standards: UL 508, CSA, EN/IEC 60947-1/5-4/5-1
- Environmental Ratings: IP66/IP67/IP69K, -40°C to 70°C operating temperature
- Certifications: UL Listed, CSA
- Resistance to Vibrations and Shocks: IEC 60068-2-6/-2-27
Buy the Buy Schneider Electric Series XB5 Pilot Light Part Number XB5FVG6 Online
Secure your industrial signaling needs by purchasing the Schneider Electric Series XB5 Pilot Light XB5FVG6 online today. This durable flush-mounted indicator features a protected blue LED light source, rated for 110-120 V AC, with long-lasting service life of 100,000 hours at 25°C. Designed for rugged industrial environments, it offers IP66/IP67/IP69 protection, ensuring dependable operation in demanding conditions. Easy to install with screw clamp terminals, it is certified UL and CSA compliant, making it the perfect choice for automation panels and process control applications.
Order your Schneider Electric Series XB5 XB5FVG6 Pilot Light today and enhance your control systems with reliable lighting for industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric XB5FVG6?
You can click on the BUY or RFQ button to purchase XB5FVG6 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part XB5FVG6?
You can download the XB5FVG6 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of XB5FVG6?
Schneider Electric
