Schneider Electric XB5FVM4 Industrial Pilot Light
The Pilot light is a flush-mounted, red plastic signaling device with an integral LED and plain lens, designed for 230-240 V AC supply. It features a built-in LED light source with a long service life of 100,000 hours, high resistance to high-pressure washing up to 7,000,000 Pa, and standard screw clamp terminals. This round signaling unit, classified for IP66, IP67, and IP69 protection, has a mounting diameter of 1.20 inches (30.5 mm) and is suitable for industrial alert systems and control panels, meeting IEC, UL, and CSA standards.
Schneider Electric XB5FVM4 Industrial Pilot Light Specifications:
- Shape of signaling unit Round
- Light source Protected LED
- Light source color Red
- Rated supply voltage 230...240 V AC 50/60 Hz
- Supply voltage limits 195...264 V AC
- Current consumption 14mA
- Service life 100,000 hours at 25°C
- Protection IP66, IP67, IP69, NEMA 13, NEMA 4X
- Operating temperature 0 to 158 °F (-40 to 70 °C)
- Mounting diameter 1.20 inches (30.5 mm)
- Base material Plastic
- Head type Built-in-flush
- Bezel material Dark grey plastic
- Terminal types Screw clamp, <= 2 x 1.5 mm², 1 x 0.22 to 2.5 mm²
- Resistance to high pressure washer 7,000,000 Pa at 55°C
- Certifications UL Listed, CSA
- Standards IEC 60947-1, IEC 61000-4-4, IEC 61000-4-3, IEC 60068-2-6, IEC 60068-2-27
- Environmental ratings IP66/IP67/IP69K, NEMA 13/NEMA 4X
- Impact resistance 50 gn for 18 ms
- Vibration resistance 5 gn 12-500 Hz
- Resistance to electrostatic discharge 6 kV contact, 8 kV air
- Electromagnetic emission Class B IEC 55011
Buy the Schneider Electric Series XB5 Pilot Light: XB5FVM4
Purchase your Schneider Electric Series XB5 pilot light XB5FVM4 today online and ensure your control systems are equipped with durable, high-quality LED indicator lights. Designed for industrial environments, this flush-mounted red signaling device features a robust plastic body, integrated LED, and excellent resistance to high-pressure washing, vibrations, and electrical interference. Its IP66, IP67, and IP69 ratings guarantee superior protection against dust and moisture, making it ideal for heavy-duty applications in automation, machinery, and control panels. Enjoy quick online ordering and reliable delivery for your projects.
Order your Schneider Electric Series XB5 pilot light XB5FVM4 today and enhance the visibility and safety of your control panels with reliable LED signaling.
