Schneider Electric XB5FVM5 Industrial Pilot Light
Compact and reliable pilot light designed for industrial applications, featuring a built-in orange LED indicator. Suitable for flush mounting, it supports 230-240 V AC operation with IP66/IP67/IP69/IP69K protection ratings, ensuring durability against dust, water, and high-pressure wash. The unit includes a dark grey plastic bezel and fixing collar, has a mounting diameter of 30.5 mm, and a life span of 100,000 hours. It offers screw clamp terminals with a rated insulation voltage of 250 V and complies with UL, CSA, IEC standards, making it ideal for control panels and machinery signaling systems.
Schneider Electric XB5FVM5 Industrial Pilot Light Specifications:
- Mounting diameter: 30.5 mm
- Head type: Built-in-flush
- Shape: Round
- Cap color: Orange
- Light source: Protected LED
- Rated supply voltage: 230-240 V AC 50/60 Hz
- Height: 42 mm
- Maximum Width: 36.6 mm
- Depth: 55 mm
- Connections: Screw clamp terminals, <= 2 x 1.5 mm²
- Insulation voltage: 250 V (pollution degree 3)
- Rated impulse withstand voltage: 4 kV
- Signaling type: Steady
- Supply voltage limits: 195-264 V AC
- Current consumption: 14 mA
- Service life: 100,000 h
- Protection ratings: IP66, IP67, IP69, IP69K, NEMA 13, NEMA 4X
- Vibration resistance: 5 gn
- Shock resistance: 50 gn
- Resistance to transients: 2 kV IEC 61000-4-4
- Electromagnetic compatibility: IEC 61000-4-2, IEC 61000-4-3
- Certifications: UL, CSA
- Operating temperature: 0 to 70°C
- Material: Plastic
- Environmental resistance: High-pressure wash, UV and chemical resistance
Buy the Schneider Electric XB5FVM5 – Reliable Signaling Light for Industrial Applications
Order the Schneider Electric XB5FVM5 industrial pilot light online today for robust operation and reliable status indication in harsh environments. Featuring a durable plastic construction, IP69K rating, and an efficient built-in LED, it ensures long-term performance and safety in demanding control panels. Easy to install with screw clamp terminals, it supports 230-240 V AC power supply. Perfect for automation, machinery, and facility signaling, this pilot light offers ease of use and maintenance, vital for efficient industrial operations.
Get Schneider Electric XB5FVM5 today—built for durable signaling and long-lasting performance in demanding control systems.
