Schneider Electric XB5FW31B5 Industrial Control Push Button
The illuminated push button is a flush-mounted, plastic device with a white head and integral LED, rated for 24 V AC/DC. It features one normally open and one normally closed contact, with a spring return operator profile and protected LED light source. Its compact design measures approximately 42 mm in height, 36.6 mm in width, and 55 mm in depth. Designed with screw clamp terminals, it is suitable for industrial control applications, offering high durability with 10 million cycles, high pressure wash resistance, and compliance with IEC and UL standards for safety and reliability.
Schneider Electric XB5FW31B5 Industrial Control Push Button Specifications:
- Mounting diameter: 30.5 mm
- Shape: Round
- Head type: Built-in-flush, Plain lens
- Contacts: 1NO + 1NC, Slow-break, Silver alloy contact material
- Light source: Protected Integral LED, rated for 24 V AC/DC
- Operating travel: 1.5 mm NC, 2.6 mm NO, 4.3 mm total
- Operating force: 3.5 N NC, 3.8 N NO
- Mechanical durability: 10,000,000 cycles
- Tightening torque: 0.8 to 1.2 N.m
- Environmental ratings: IP66, IP67, IP69K; NEMA 13, 4X; IK10
- Standards: IEC 60947-1, IEC 60947-5-1, UL 508, CSA, JIS C8201-5-1
- Vibration resistance: 5 gn
- Shock resistance: 30 to 50 gn
- Resistance to fast transients: 2 kV
- Resistance to electromagnetic fields: 9.14 V/m
- Rated operational current: 3 A at 240 V, AC-15, 6 A at 120 V, AC-15
- Rated insulation voltage: 600 V
- Supply voltage: 19.2 to 30 V DC, 21.6 to 26.4 V AC
- Current consumption: 18 mA
- Service life: 100,000 hours
- Packaging: 1 piece per package, weight 1 lb (0.45 kg)
Buy the Buy Schneider Electric Control Component Part Number XB5FW31B5 Online
Enhance your control panel with this high-quality, durable illuminated push button. Featuring integral LED illumination, IP69K protection, and long-lasting mechanical life, it ensures reliable operation in demanding environments. Easy to install with screw clamp terminals and compliant with international safety standards, this control component is ideal for automation and industrial control systems. Purchase online today to benefit from quick delivery, superior quality, and excellent value for your automation needs.
Buy Schneider Electric XB5FW31B5 now and experience unmatched reliability, high durability, and seamless industrial control performance.
Frequently Asked Questions
Where can I buy Schneider Electric XB5FW31B5?
You can click on the BUY or RFQ button to purchase XB5FW31B5 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part XB5FW31B5?
You can download the XB5FW31B5 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of XB5FW31B5?
Schneider Electric
