Schneider Electric XB5FW33B5 Industrial Push Button
The illuminated push button is designed for industrial control panels, featuring a flush-mount plastic construction with a green lens and integral LED, operating at 24 V AC/DC. It includes one normally open and one normally closed contact, with screw clamp terminals for reliable wiring. Its IP66/IP67/IP69 protections ensure durability in harsh environments. Suitable for automation and machinery control, it offers a lifespan of 10 million cycles, with resistant materials to high-pressure washers, vibrations, and electromagnetic interference, making it ideal for industrial applications requiring robust, easily installed push buttons.
Schneider Electric XB5FW33B5 Industrial Push Button Specifications:
- Mounting diameter: 1.20 in (30.5 mm)
- Head type: Built-in-flush, round
- Operator profile: Green flush, unmarked, with plain lens
- Contacts: 1 Normally Open + 1 Normally Closed, slow-break operation
- Light source: Protected LED, integral
- Rated supply: 24 V AC/DC, 50/60 Hz
- Contact material: Silver alloy (Ag/Ni)
- Screw clamp terminals: <= 2 x 1.5 mm? with cable end conforming to EN/IEC 60947-1
- Environmental protection: IP66, IP67, IP69K, NEMA 13, NEMA 4X
- Vibration resistance: 5 gn (2-500 Hz)
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Electrical durability: 1,000,000 cycles (AC-15, 2-4 A, 120-230 V), 1,000,000 cycles (DC-13, 0.2-0.5 A, 24 V)
- Service life: 100,000 hours at rated voltage and 25°C
- Standards: EN/IEC 60947-1, UL 508, JIS C8201-5-1, CSA, IEC 61000-4-5, IEC 61000-4-2
Buy the Schneider XB5FW33B5 – Reliable Industrial Push Button for Control Panels
Order the Schneider XB5FW33B5 industrial push button today to ensure durable, reliable control in your machinery or automation system. Featuring a robust plastic construction, integral LED illumination, and IP66/IP67/IP69K protection ratings, this flush-mounted green push button is designed to withstand harsh environments. Its easy wiring with screw clamp terminals and long electrical lifespan of over a million cycles make it ideal for demanding applications. Purchase online now for fast delivery and seamless integration into your control solutions.
Buy Schneider XB5FW33B5 now and experience unmatched durability and reliable control in industrial applications.
Frequently Asked Questions
Where can I buy Schneider Electric XB5FW33B5?
You can click on the BUY or RFQ button to purchase XB5FW33B5 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part XB5FW33B5?
You can download the XB5FW33B5 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of XB5FW33B5?
Schneider Electric
