Schneider Electric XB5FW33G5 Illuminated Push Button
The illuminated push button features a flush-mounted plastic design with a green color and integral LED indicator, rated for 110-120 V AC. Suitable for industrial control panels, it offers a round shape with a built-in head, 1 NO + 1 NC contacts, and a spring return operator profile. The button is IP66/IP67/IP69 rated, resistant to high-pressure washing, and conforms to multiple international standards including UL and IEC. Its compact dimensions are 1.65 inches high, with a mounting diameter of 1.20 inches, ensuring durability, reliable switching, and easy installation in demanding environments.
Schneider Electric XB5FW33G5 Illuminated Push Button Specifications:
- Mounting diameter: 1.20 inches (30.5 mm)
- Height: 1.65 inches (42 mm)
- Maximum width: 1.44 inches (36.6 mm)
- Depth: 2.17 inches (55 mm)
- Operating travel: 0.06 inches (1.5 mm) NC, 2.6 mm NO, 4.3 mm total
- Supply voltage: 110...120 V AC 50/60 Hz
- Light source: Protected integral LED, green color
- Contacts type: 1 NO + 1 NC, Silver alloy contact material
- Contact operation: Slow-break
- Connections: Screw clamp terminals, <= 2 x 1.5 mm² or 1 x 0.22...2.5 mm²
- IP protection: IP66, IP67, IP69K
- Vibration resistance: 5 gn (IEC 60068-2-6)
- Shock resistance: 30 gn (IEC 60068-2-27)
- Electrical durability: 1,000,000 cycles
- Certifications: UL Listed, CSA
- Standards: EN/IEC 60947-1, UL 508, JIS C8201-5-1, IEC 61000-4-2/3/4, EN 55011
Buy the Schneider Electric Series Harmony XB5 Illuminated Push Button: XB5FW33G5
Order the Schneider Electric XB5FW33G5 illuminated push button online today for seamless integration into your industrial control panels. Its rugged plastic construction, green LED indicator, rated for 110-120V AC, and IP69K protection ensure reliable operation in harsh environments. Designed with a flush-mounted round shape, it features 1 NO + 1 NC contacts, screw clamp terminals for secure wiring, and a spring return operator profile for easy operation. Ideal for automation, control stations, and manufacturing applications, this durable push button guarantees long-lasting performance and easy installation.
Get Schneider Electric XB5FW33G5 today—built for durability and reliable industrial control functionality.
Frequently Asked Questions
Where can I buy Schneider Electric XB5FW33G5?
You can click on the BUY or RFQ button to purchase XB5FW33G5 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part XB5FW33G5?
You can download the XB5FW33G5 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of XB5FW33G5?
Schneider Electric
