Schneider Electric XB5FW33M5 Industrial Control Push Button
The illuminated push button is a robust, flush-mounted device with a green plastic body and integral LED indicator, designed for industrial control applications. It features a 30.5 mm mounting diameter, built-in-flush head, and a spring-return operator profile for reliable operation. Equipped with screw clamp terminals conforming to EN/IEC standards, it supports multiple connection options. The device withstands high-pressure washing up to 7,000,000 Pa, has a rated voltage of 220-240 V AC, and offers durability of over 10 million mechanical cycles. Its IP66, IP67, and IP69K ratings ensure excellent environmental protection suitable for harsh environments.
Schneider Electric XB5FW33M5 Industrial Control Push Button Specifications:
- Mounting diameter: 30.5 mm
- Head type: Built-in-flush
- Shape: Round
- Color: Green
- Illumination: Integral LED
- Contacts: 1NO + 1NC, Slow-break
- Connection terminals: Screw clamp, <= 2 x 1.5 mm², without cable, conforming to EN/IEC 60947-1
- Light source: Protected LED
- Rated supply voltage: 220-240 V AC 50/60 Hz
- Height: 42 mm
- Maximum width: 36.6 mm
- Depth: 55 mm
- Resistance to high-pressure washer: 7,000,000 Pa at 55°C, 0.1m distance
- Contacts material: Silver alloy (Ag/Ni)
- Short-circuit protection: 10 A gG fuse
- Insulation voltage: 600 V
- Impulse withstand voltage: 6 kV
- Operational current: 3 A (240 V AC), 6 A (120 V AC)
- Electrical durability: 1,000,000 cycles
- IP Protection: IP66, IP67, IP69K
- Ambient operating temperature: -40°C to +70°C
- Vibration resistance: 5 gn
- Shock resistance: 30-50 gn
- Standards: EN/IEC 60947-1, UL 508, CSA, JIS C8201-5-1
- Certifications: UL Listed, CSA
- Environmental: RoHS compliant, Mercury free, compliant with REACh
Buy the Schneider Series XB5 Illuminated Push Button: XB5FW33M5
Order the Schneider Electric industrial control push button XB5FW33M5 online today and experience reliable operation with its robust design, integral LED, and IP69K protection. This green illuminated flush-mounted button features a 30.5 mm diameter, high-pressure wash resistance up to 7,000,000 Pa, and over 1 million operating cycles for extended durability. Suitable for harsh industrial environments, it meets strict safety standards, ensuring safe and effective control for automation and machinery applications. Purchase now for quick delivery and seamless integration into your control systems.
Get Schneider XB5FW33M5 today—built for industrial durability and reliable control in harsh environments.
