Schneider Electric XB5FW34B5 Illuminated Push Button
The illuminated push button is a flush-mounted device made of durable plastic, featuring a red operator with integral LED illumination suitable for 24 V AC/DC systems. It has a round shape with a 30.5 mm mounting diameter, designed for industrial control panels. The button includes a spring-return operator profile, with a contact arrangement of 1 normally open and 1 normally closed contact, and features robust screw clamp terminals for secure wiring. Rated for high pressure wash resistance, it is certified for various international standards and ideal for demanding automation environments, providing reliable signaling and control with long mechanical durability.
Schneider Electric XB5FW34B5 Illuminated Push Button Specifications:
- Mounting Diameter: 30.5 mm (1.20 in)
- Shape: Round
- Head Type: Built-in-flush
- Operator Profile: Red flush, unmarked with plain lens
- Contacts: 1NO+1NC, Slow-break, Silver alloy contacts
- Light Source: Integral LED, protected
- Rated Voltage: 24 V AC/DC, 50/60 Hz
- Contact Operation: Slow-break
- Operating Travel: 0.06 in (1.5 mm) NC, 2.6 mm NO, total 4.3 mm
- Operating Force: 3.5 N (NC), 3.8 N (NO)
- Mechanical Durability: 10 million cycles
- Tightening Torque: 0.8–1.2 N·m
- Ingress Protection: IP66, IP67, IP69K
- Resistance to High-Pressure Washer: 7,000,000 Pa at 55°C
- Switching Capacity: 10 A cartridge fuse gG EN/IEC 60947-5-1
- Vibration Resistance: 5 gn (2–500 Hz)
- Shock Resistance: 30 gn (18 ms), 50 gn (11 ms)
- Environmental: Able to operate from 0 to 70°C
- Standards: EN/IEC 60947-1, UL 508, CSA, JIS C8201-5-1
- Certifications: UL Listed, CSA
- Protection Class: Class II conforming to IEC 60536
Buy the Buy Schneider Electric Illumined Push Button Part Number XB5FW34B5 Online
Enhance your control panels with this high-quality illuminated push button featuring a red flush-mounted design, integral LED lighting, and a robust IP69K protection rating. It is crafted for reliable operation in harsh environments, including high-pressure wash settings, with a long mechanical life of 10 million cycles. Easy to install with screw clamp terminals and certified for various international standards, this device provides safe, durable, and efficient signaling for industrial automation and control systems. Purchase online today for quick and trusted delivery.
Buy Schneider Electric XB5FW34B5 now and experience reliable signaling and durable control in demanding industrial environments.
