Schneider Electric XB5FW34G5 Illuminated Push Button
This illuminated push button features a flush-mounted plastic design with a red color and integral LED, rated for 110-120 V AC. It has one normally open (NO) and one normally closed (NC) contact, a built-in head, and is suitable for industrial control panels. The device includes screw clamp terminals, a durable silver alloy contact material, and is rated for various operational currents and mechanical cycles. It offers high resistance to environmental factors, including IP66/IP67/IP69 protection ratings, and complies with IEC standards, ensuring reliable operation in demanding industrial environments.
Schneider Electric XB5FW34G5 Illuminated Push Button Specifications:
- Mounting diameter: 30.5 mm (1.20 in)
- Head type: Built-in-flush, round
- Bezel and collar material: Plastic, dark grey
- Operator profile: Red flush, unmarked with plain lens
- Light source: Protected LED, integral bulb base
- Rated supply voltage: 110-120 V AC 50/60 Hz
- Contacts: 1 NO + 1 NC, slow-break operation
- Connection: Screw clamp terminals, <= 2 x 1.5 mm² with cable
- Operating travel: 1.5 mm (NC), 2.6 mm (NO), total 4.3 mm
- Operating force: 3.5 N (NC), 3.8 N (NO)
- Mechanical durability: 10,000,000 cycles
- Environmental ratings: IP66, IP67, IP69K, NEMA 4X, 13
- Vibration resistance: 5 gn
- Shock resistance: 30 gn (18 ms)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Approval standards: IEC 60947-1, UL 508, JIS C8201-5-1
- Temperature range for operation and storage: -40°C to +70°C
- Certifications: UL Listed, CSA
- Dielectric withstand voltage: 600 V
- Electrical durability: 1,000,000 cycles at specified currents
- Signaling type: Steady, with supply voltage limits 100-132 VAC
- Environmental protection: Meets IP66/IP67/IP69K, NEMA 4X
Buy the Schneider XB5FW34G5 – Reliable Illumination Push Button for Industrial Applications
Enhance your control panels with this robust illuminated push button, rated for 110-120 V AC, featuring a durable plastic construction, integral LED, and comprehensive environmental protections including IP69K. With a modern design, easy screw clamp terminals, and high mechanical durability, it ensures reliable operation in harsh industrial environments. Perfect for applications requiring safety signaling and operator feedback, this device adheres to IEC standards and is UL and CSA certified, making it an ideal choice for industrial automation and control panels.
Buy Schneider XB5FW34G5 now and experience unmatched reliability and performance in industrial control systems.
