Schneider Electric XB5FW35B5 Illuminated Push Button
This illuminated push button features a flush-mounted design with a durable plastic construction and orange operation profile. It includes an integral LED light source rated for 24 V AC/DC, with 1 normally open and 1 normally closed contact, suitable for industrial control systems. With a mounting diameter of 30.5 mm, it complies with international standards such as EN/IEC 60947-1 and UL 508. Designed for high-pressure wash resistance up to 7,000,000 Pa and a long service life of 100,000 hours, it provides reliable operation in challenging environments. Its IP66/IP67/IP69 and NEMA 4X protection ratings ensure excellent environmental sealing, making it versatile for various industrial applications.
Schneider Electric XB5FW35B5 Illuminated Push Button Specifications:
- Mounting diameter: 30.5 mm
- Head type: Built-in-flush
- Shape: Round
- Color: Orange, operator profile flush, unmarked
- Contacts: 1NO+1NC, slow-break operation
- Light source: Integral LED, protected
- Rated voltage: 24 V AC/DC
- Maximum width: 36.6 mm
- Height: 42 mm, Depth: 55 mm
- Connection: Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming
- Material: Dark grey plastic bezel, plastic fixing collar
- Pressure resistance: 7,000,000 Pa at 55°C
- Ingress protection: IP66, IP67, IP69K
- Protection ratings: NEMA 13, 4X
- Standards: EN/IEC 60947-1, UL 508, CSA
- Vibration resistance: 5 gn
- Shock resistance: 30 gn (18 ms)
- Electromagnetic compatibility: IEC 61000-4-2/4-4/4-3, IEC 55011
- Service life: 100,000 hours
- Operating temperature: -40°C to +70°C
Buy the Buy Schneider Electric Illuminated Push Button Part Number XB5FW35B5 Online
Order the Schneider Electric illuminated push button XB5FW35B5 online today and enjoy a highly reliable industrial control component. Featuring a durable plastic construction, integral LED illumination, IP69K sealing, and high-pressure wash resistance, it is suitable for demanding environments. With a mounting diameter of 30.5 mm, it includes 1 normally open and 1 normally closed contact, rated for 24 V AC/DC. Perfect for control panels requiring long service life, safety standards compliance, and high environmental resistance, ensuring seamless integration into your automation system.
Buy Schneider Electric XB5FW35B5 now and experience unmatched reliability and durability in industrial control equipment.
