Schneider Electric XB5FW35G5 Illuminated Push Button
This illuminated push button switch features a flush-mounted plastic orange operator with a built-in LED, rated for 110-120 V AC. It includes a round head with a spring return profile, integrating one normally open and one normally closed contact. Its construction includes a dark grey plastic bezel and fixing collar, with screw clamp terminals for easy wiring. Designed for industrial applications, it withstands high-pressure washing, offers long mechanical durability of 10 million cycles, and conforms to IEC 60947 standards, making it ideal for control panels and machinery automation.
Schneider Electric XB5FW35G5 Illuminated Push Button Specifications:
- Mounting diameter: 30.5 mm (1.20 in)
- Head type: Built-in-flush, round shape
- Operator profile: Orange flush, unmarked, with plain lens
- Contacts: 1 normally open (NO) and 1 normally closed (NC), Slow-break operation
- Light source: Protected LED, integral
- Rated supply voltage: 110-120 V AC at 50/60 Hz
- Contact material: Silver alloy (Ag/Ni)
- Screw clamp terminals: <= 2 x 1.5 mm² with cable end, 1 x 0.22...2.5 mm² without cable end
- Height: 42 mm (1.65 in), Width: 36.6 mm (1.44 in), Depth: 55 mm (2.17 in)
- Resistance to high-pressure washer: 7,000,000 Pa at 55°C, 0.1 m distance
- Degree of protection: IP66/IP67/IP69K, NEMA 13, 4X
- Environmental ratings: Operating temperature -40°C to +70°C, Vibration resistance 5 gn, Shock resistance 30/50 gn
Buy the Buy Schneider Electric Illuminated Push Button Part Number XB5FW35G5 Online
Purchase the Schneider Electric Illuminated Push Button XB5FW35G5 online today and enjoy fast delivery. Its robust plastic construction, IP69K rating, and long mechanical lifespan of 10 million cycles ensure dependable operation in demanding industrial settings. Easily wired with screw clamp terminals and featuring a protected LED light source, this control device is perfect for machinery and control panels requiring durable, high-quality automation components. Invest now for unmatched reliability and streamlined installation.
Buy Schneider Electric XB5FW35G5 now and experience reliable performance with high durability and IP69 protection for industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric XB5FW35G5?
You can click on the BUY or RFQ button to purchase XB5FW35G5 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part XB5FW35G5?
You can download the XB5FW35G5 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of XB5FW35G5?
Schneider Electric
