Schneider Electric XB5FW35M5 Illuminated Push Button
This illuminated push button switch features a round, orange plastic bezel with integral LED, designed for flush mounting with a 30.5 mm diameter. Rated for 230-240 V AC, it includes one normally open and one normally closed contact, with slow-break operation suitable for industrial control panels. The device has a mechanical durability of 10 million cycles, IP66/IP67/IP69 protection, and is compliant with multiple safety standards. Its high-quality contacts are silver alloy, ensuring reliable switching in demanding environments, with a built-in LED for visibility and a user-friendly operator profile.
Schneider Electric XB5FW35M5 Illuminated Push Button Specifications:
- Bezel Material: Dark grey plastic
- Mounting Diameter: 30.5 mm (1.20 in)
- Head Type: Built-in-flush
- Shape: Round
- Contacts: 1NO+1NC, Slow-break operation, Silver alloy material
- Light Source: Integrated LED, Voltage: 220-240 V AC 50/60 Hz
- Color: Orange with plain lens
- Dimensions: Height 42 mm (1.65 in), Width 36.6 mm (1.44 in), Depth 55 mm (2.17 in)
- Screw Terminal: <= 2 x 1.5 mm² with cable, 1 x 0.22-2.5 mm² without cable
- Protection: IP66/IP67/IP69, NEMA 13, NEMA 4X
- Material: Plastic, Seal: TH protective treatment
- Operating Travel: 1.5 mm (NC), 2.6 mm (NO), Total 4.3 mm
- Operating Force: 3.5 N (NC), 3.8 N (NO)
- Mechanical Durability: 10 million cycles
- Temperature Range: -40°C to +70°C
- Standards: IEC 60947-1, IEC 60947-5-1, UL 508, CSA, JIS
- Environmental Resistance: Vibration 5 gn, Shock 30-50 gn, Resistance to electromagnetic interference, static discharge, fast transients
- Certifications: UL Listed, CSA, Green Premium
Buy the Buy Schneider Electric Illuminated Push Button Part Number XB5FW35M5 Online
Purchase the Schneider Electric illuminated push button XB5FW35M5 online today to enhance your control panel solutions. Featuring a robust plastic bezel, integrated LED indicator, IP66/IP69 protection, and durable operation for over 10 million cycles, this high-quality control component is suitable for demanding industrial environments. Easy to install with screw clamp terminals and compliant with international safety standards, this device guarantees reliable switching and visibility, making it an essential addition for automation and control systems.
Buy Schneider Electric XB5FW35M5 now and experience unmatched reliability and industrial-grade durability with high protection standards.
