Schneider Electric XB5FW36G5 Illuminated Push Button
The illuminated push button is a flush-mounted plastic device designed for industrial control applications. It features a blue integral LED, built-in flush head, and a round shape with a 30.5 mm mounting diameter. Equipped with 1 normally open and 1 normally closed contact, it operates on 110-120 V AC at 50/60 Hz. The device supports screw clamp terminals, has a maximum height of 42 mm, and offers a steady signaling type with a service life of 100,000 hours. Its robust design ensures resistance to high-pressure washing, vibration, and electromagnetic interference, conforming to multiple international standards for safety and durability.
Schneider Electric XB5FW36G5 Illuminated Push Button Specifications:
- Mounting diameter: 30.5 mm
- Height: 42 mm
- Maximum width: 36.6 mm
- Depth: 55 mm
- Light source: Protected LED
- Rated voltage: 110-120 V AC 50/60 Hz
- Contacts: 1NO+1NC, slow-break operation
- Contact material: Silver alloy (Ag/Ni)
- Connection: Screw clamp terminals <= 2 x 1.5 mm²
- IP degree of protection: IP66/IP67/IP69K
- NEMA ratings: NEMA 13, NEMA 4X
- Vibration resistance: 5 gn (IEC 60068-2-6)
- Shock resistance: 30 gn (IEC 60068-2-27)
- Electrical durability: 1,000,000 cycles
- Operating travel: 1.5 mm (NC), 2.6 mm (NO)
- Operating force: 3.5-3.8 N
- Environmental ratings: -40°C to +70°C storage and operation
- Standards: IEC 60947-1, UL 508, JIS C8201-5-1, CSA, IEC 61000-4-2/3/4
- Certifications: UL Listed, CSA
Buy the Buy Schneider Electric Illuminated Push Button Part Number XB5FW36G5 Online
Purchase the Schneider Electric illuminated push button XB5FW36G5 online today to ensure reliable industrial control operations. This durable, flush-mounted plastic device features a blue LED, built-in head, and robust screw clamp terminals. Compatible with 110-120 V AC voltage, it offers steady signaling with a service life of 100,000 hours. Its IP66/IP67/IP69K rated protection ensures resistance to harsh environments, including water and dust. Ideal for automation panels, control stations, and industrial systems requiring reliable visual indication and long-lasting performance.
Get Schneider Electric XB5FW36G5 today—built for industrial control with durable plastic housing and integrated LED signaling.
Frequently Asked Questions
Where can I buy Schneider Electric XB5FW36G5?
You can click on the BUY or RFQ button to purchase XB5FW36G5 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part XB5FW36G5?
You can download the XB5FW36G5 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of XB5FW36G5?
Schneider Electric
