Schneider Electric XB5FW36M5 Illuminated Push Button
The illuminated push button features a durable plastic construction with a blue LED indicator, suitable for industrial control panels. It is flush mounted with a 30.5 mm diameter, offering reliable operation with 1 NO + 1 NC contacts featuring slow-break contact operation. Compatible with 220-240 V AC supply, it has built-in LED illumination, a screw clamp terminal connection, and IP66/IP67/IP69 protection ratings. It withstands mechanical durability for 10 million cycles, high-pressure wash resistance, and complies with IEC, UL, and CSA standards, making it ideal for harsh industrial environments.
Schneider Electric XB5FW36M5 Illuminated Push Button Specifications:
- Mounting diameter: 30.5 mm
- Height: 42 mm
- Width: 36.6 mm
- Depth: 55 mm
- Contact type: 1NO + 1NC, slow-break
- Contact material: Silver alloy (Ag/Ni)
- Light source: Protected LED
- Rated voltage: 220-240 V AC 50/60 Hz
- Surge withstand: 1 kV IEC 61000-4-5
- Device rating: IP66/IP67/IP69, NEMA 13, NEMA 4X
- Mechanical durability: 10 million cycles
- Operating force: 3.8 N
- Vibration resistance: 5 gn
- Shock resistance: 30 gn
- Temperature range: -40°C to +70°C
- Standards: IEC 60947-1, IEC 60947-5-1, UL 508, CSA, JIS
- Certifications: UL Listed, CSA
Buy the Schneider XB5FW36M5 – Reliable Industrial Push Button for Control Panels
Order the Schneider XB5FW36M5 illuminated push button online today for reliable control in demanding industrial environments. Featuring a durable plastic housing with integrated LED illumination, it offers IP66/IP67/IP69 protection against dust and water. The flush-mounted design with 30.5 mm diameter, 1 NO + 1 NC contacts, and rated for 220-240 V AC ensures smooth operation and longevity. Perfect for control stations, automation panels, and harsh settings requiring high durability and compliance with international standards.
Get Schneider XB5FW36M5 today—built for precision, durability, and harsh industrial environments with IP69 protection.
Frequently Asked Questions
Where can I buy Schneider Electric XB5FW36M5?
You can click on the BUY or RFQ button to purchase XB5FW36M5 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part XB5FW36M5?
You can download the XB5FW36M5 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of XB5FW36M5?
Schneider Electric
