Schneider Electric XB6DF5B1B Control Push-Button
This complete illuminated push-button features a yellow rectangular flush design with a latching operator, LED illumination, and 1NO silver alloy contacts. Suitable for control panels, it operates at 12–24 V AC/DC, with a compact size of 0.71 in height and 0.94 in width, mounted via 16 mm diameter. It offers durability of 1,000,000 cycles, IP65 protection, and compliance with international standards such as UL, CSA, and EN/IEC. Ideal for industrial control environments requiring reliable, steady signaling and quick connection with Faston terminals.
Schneider Electric XB6DF5B1B Control Push-Button Specifications:
- Shape of signaling unit head: Rectangular
- Bezel material: Plastic
- Mounting diameter: 16 mm
- Height: 0.71 in (18 mm)
- Width: 0.94 in (24 mm)
- Depth: 2.24 in (57 mm)
- Light source: LED, integral bulb base
- Rated supply voltage: 12–24 V AC/DC
- Contacts: 1NO, Silver alloy (Ag/Ni), slow-break operation
- Contact operation: ‘Steady’ signaling
- Operating force: 3.5 N
- Operating travel: 0.04 in (1 mm) electrical change
- Electrical durability: 1,000,000 cycles
- IP degree of protection: IP65
- Environmental rating: TC protective treatment
- Certifications: UL, CSA, EN/IEC 60947-1, EN/IEC 60947-5-1
- NEMA ratings: 13, 4, 4X
- Signaling type: Steady
- Surge withstand: 1 kV contact, 2 kV air
- Resistance to electromagnetic fields: 9.14 V/m
- Vibration resistance: +/- 3 mm 2...500 Hz
- Shock resistance: 30 gn 18 ms
- Temperature range: -25°C to 70°C
- WEEE and RoHS compliant
Buy the Harmony XB6 – Reliable Control Push-Button for Industrial Applications
Enhance your control systems with this durable, yellow rectangular illuminated push-button ideal for industrial control panels. Featuring LED illumination, IP65 protection, and robust silver alloy contacts, it withstands 1,000,000 cycles. Easy to mount with 16 mm diameter and rated for 12–24 V AC/DC. Suitable for demanding environments with EN/IEC and UL standards compliance, making it an excellent choice for reliable operation in factory automation, control stations, and machinery. Buy online now for quick, dependable delivery.
Order your Harmony XB6 Series XB6DF5B1B illuminated push-button today and ensure reliable control with durable design and IP65 protection for industrial projects.
Frequently Asked Questions
Where can I buy Schneider Electric XB6DF5B1B?
You can click on the BUY or RFQ button to purchase XB6DF5B1B from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part XB6DF5B1B?
You can download the XB6DF5B1B datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of XB6DF5B1B?
Schneider Electric
