Schneider Electric ZB4BVM1 Industrial Indicator Light
The ZB4BVM1 is a white light block with an integral body and fixing collar designed for industrial control applications. It features a protected LED light source operating at 230 to 240V AC, with a service life of 100,000 hours at 25°C. Made from zamak, the device includes screw clamp terminals, and is compatible with various mounting and connection options. It conforms to multiple international standards, offering reliable operation in diverse environments with robust shock and vibration resistance. Suitable for automation and safety signaling, this indicator provides a steady signal in control panels.
Schneider Electric ZB4BVM1 Industrial Indicator Light Specifications:
- Light source: Protected LED, White colour
- Supply Voltage: 230-240 V AC, 50/60 Hz
- Rated insulation voltage: 600 V (pollution degree 3)
- Impulse withstand voltage: 6 kV
- Dimensions: Width 30mm, Height 47mm, Depth 37mm
- Tightening torque: 0.8-1.2 N.m
- Material: Zamak fixing collar
- Connection: Screw clamp terminals, faston connectors, or PCB
- Service life: 100,000 hours at 25°C
- Vibration resistance: 5 gn (2-500 Hz)
- Shock resistance: 50 gn (11 ms), 30 gn (18 ms)
- Surge withstand: 1 kV
- Protection level: IEC 60536 Class
- Standards: UL, CSA, EN/IEC 60947 and others
- Operating temperature: -25°C to +70°C
- Storage temperature: -40°C to +70°C
- Certifications: UL listed, CSA approved, BV, DNV, RINA, GLO
Buy the Schneider Series ZB4 White Indicator: ZB4BVM1
Purchase the Schneider ZB4BVM1 white LED indicator online today to ensure reliable signaling in your automation systems. Crafted with high-quality materials like zamak and protected LED light source, it guarantees long service life and durability. Its compact size, standard compliance, and versatile mounting options make it suitable for various industrial environments. Easy to install with screw clamp terminals or plug-in connectors, this indicator ensures clear, steady signals for control panels. Upgrade your safety and operational signaling with this robust, high-performance indicator from Schneider Electric.
Order your Schneider Series ZB4BVM1 indicator today and enhance your control panels with reliable, durable signaling solutions.
