Schneider Electric ZB4BW0B41 Indicator Light
This is a reliable industrial indicator light with a red LED source designed for control panels. It features a durable Zamak fixing collar, integrated light source, and a compact 30mm width by 47mm height design. The device operates on 24V AC/DC, with screw clamp terminals for secure connections. Its slow-break contact operation ensures safety and longevity, supporting up to 5 million mechanical cycles. It complies with international standards including IEC and UL, making it suitable for demanding industrial environments requiring clear visual signaling and robust construction.
Schneider Electric ZB4BW0B41 Indicator Light Specifications:
- Range of product: Harmony XB4
- Device type: Complete body/contact assembly and light block
- Light source: Protected LED, red color, integral bulb base
- Supply voltage: 24 V AC/DC, 50/60 Hz
- Overall dimensions: Width 30 mm, Height 47 mm
- Contacts type: 1NO, slow-break operation
- Material: Zamak fixing collar, silver alloy contacts, screw clamp terminals
- Connection: 2x 1.5 mm² with cable end, 1x 0.22 mm² without cable end
- Operating travel: 2.6 mm (NO), total 4.3 mm
- Operating force: 2.3 N
- Mechanical durability: 5,000,000 cycles
- Certifications: UL, CSA, RINA, Lloyd’s Register, DNV, BV, GL
- Standards compliance: IEC 60947-5-1, IEC 60947-5-5, UL 508
- Environmental ratings: -40°C to 70°C ambient temperature, IP rating not specified
- Signaling: Steady light, current consumption 18 mA
- Protection class: IEC 60536, Class 1 shock protection
- Vibration resistance: 5 gn, Shock resistance: 30-50 gn
- Electrical durability: up to 1,000,000 cycles depending on load
- Warranty: 18 months
Buy the Simatic ZB4BWO0B41 – Reliable Visual Indicator for Industrial Applications
Enhance your control panel with this durable red LED indicator light, specifically designed for industrial settings. Featuring a robust Zamak body, integrated LED source, and secure screw clamp connections, it offers reliable visual signaling. Operating on 24V AC/DC, it supports up to 5 million cycles, ensuring long-term performance. Compliant with IEC and UL standards, this compact indicator light is ideal for demanding environments that require clear, steady signal indication and resilient construction. Order online today for fast, dependable delivery.
Buy ZB4BWO0B41 from Siemens now and experience unmatched reliability and performance in industrial signaling solutions.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4BW0B41?
You can click on the BUY or RFQ button to purchase ZB4BW0B41 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4BW0B41?
You can download the ZB4BW0B41 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4BW0B41?
Schneider Electric
