Schneider Electric ZB4BW0B45 Light Block Switch
This is a red light block with a body and fixing collar, featuring an LED indicator for 24V AC/DC operation. It includes 1 NO and 1 NC contacts with slow-break operation, suitable for safety and control applications. The device has a protected LED light source, integral bulb base, and direct supply. Made with zamak fixing collar, it is rated for 600V insulation and includes screw clamp terminals for reliable wiring. It supports standard operation with emphasis on durability, safety standards, and electrical reliability, ideal for industrial automation systems.
Schneider Electric ZB4BW0B45 Light Block Switch Specifications:
- Range of product: Harmony XB4
- Device type: Complete body/contact assembly and light block
- Fixing collar material: Zamak
- Contacts type: 1NO+1NC, Slow-break operation
- Light source: Red LED, Integral bulb base, Direct supply
- Rated supply voltage: 24 V AC/DC, 50/60 Hz
- Overall dimensions: Width 30mm, Height 47mm
- Connection: Screw clamp terminals 2x 1.5 mm², with cable end conforming to EN 60947-1
- Mechanical durability: 5,000,000 cycles
- Tightening torque: 0.8...1.2 N.m conforming to EN 60947-1
- Contacts material: Silver alloy (Ag/Ni)
- Short circuit protection: 10 A cartridge fuse gG
- Insulation voltage: 600 V conforming to EN 60947-1
- Impulse withstand voltage: 6 kV
- Rated operational current: 3 A at 240 V AC-15, 6 A at 120 V AC-15
- Electrical durability: 1,000,000 cycles (various loads)
- Signalling type: Steady
- Supply voltage limits: 19.2 to 30 V DC, 21.6 to 26.4 V AC
- Current consumption: 18 mA
- Service life: 100,000 hours at 25°C
- Vibration resistance: 5 g (2-500 Hz)
- Shock resistance: 30 g (18 ms) to 50 g (11 ms)
- Protection class: IEC 60536
- Standards: EN/IEC 60947-5-1, CSA, UL 508, EN/IEC 60947-5-4
- Certifications: UL listed, CSA, GL, BV, DNV, Lloyds
- Environmental: Protection against electric shock, -40°C to 70°C ambient
- Electromagnetic immunity: IEC 61000-4-5, IEC 61000-4-3, IEC 61000-4-4
- Electrostatic discharge: 6 kV contact
- Vibration resistance: 5 g
- Warranty: 18 months
Buy the Buy Schneider Electric ZB4BWOB45 Light Block Emergency Stop Switch Online
Order the Schneider Electric ZB4BWOB45 light block today for reliable performance in industrial safety systems. Featuring a robust design, integrated LED indicator, and durable construction, it ensures exceptional reliability and safety compliance. Perfect for automation and control panels, this device supports quick installation with screw clamp terminals and is rated for 24V AC/DC operation. Backed by comprehensive certifications and a 18-month warranty, it is your ideal solution for industrial signalling and control needs. Purchase online for fast delivery and expert support.
Get Schneider Electric ZB4BWOB45 light block today—built for precision and long-lasting durability in industrial safety applications.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4BW0B45?
You can click on the BUY or RFQ button to purchase ZB4BW0B45 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4BW0B45?
You can download the ZB4BW0B45 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4BW0B45?
Schneider Electric
