Schneider Electric ZB4FA0 Pushbutton Head
The ZB4FAO is a non-illuminated, flush-mounted pushbutton head with a round shape designed for industrial control panels. Made from chromium-plated metal, it features a built-in-flush head profile, a 1.20-inch (30.5 mm) mounting diameter, and dimensions of 1.44 inches in width and height, with a depth of 1.22 inches. This durable component withstands up to 10 million cycles, operates across -40°C to 70°C, and conforms to IP66, IP67, and IP69 protections, meeting IEC and UL standards for reliable performance in harsh environments.
Schneider Electric ZB4FA0 Pushbutton Head Specifications:
- Shape: Round
- Head type: Built-in-flush
- Bezel material: Chromium plated metal
- Mounting diameter: 1.20 in (30.5 mm)
- Overall dimensions: Width 1.44 in (36.6 mm), Height 1.44 in (36.6 mm), Depth 1.22 in (31 mm)
- Mechanical durability: 10,000,000 cycles
- Ambient temperature range: -40°F to 158°F (-40°C to 70°C)
- Protection ratings: IP66, IP67, IP69K, IEC 60529, UL 50E Types 12, 13, 4, 4X
- Vibration resistance: 5 gn, 10-500 Hz
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms)
- Certifications: UL Listed, CSA, CE, EAC
- Material: Chromium plated metal
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508
- Environmental resistance: Temperature -40°C to 70°C, suitable for harsh environments
- Size: 1 piece per package, Package weight: 0.45 kg
Buy the Buy Schneider Electric ZB4FAO Part Number ZB4FA0 Online
Purchase the Schneider Electric ZB4FA0 non-illuminated flush-mounted pushbutton head online today. Crafted from durable chromium-plated metal, it offers robust protection ratings IP66, IP67, and IP69K, ensuring dependable performance in harsh industrial conditions. With a 1.20-inch mounting diameter and dimensions of 1.44 inches in width and height, it withstands up to 10 million cycles. Suitable for control panels requiring high durability, this component complies with IEC, UL, and CSA standards, making it an ideal choice for reliable industrial automation solutions.
Order your Schneider Electric ZB4FA0 flush-mounted pushbutton head today and ensure reliable operation in demanding industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FA0?
You can click on the BUY or RFQ button to purchase ZB4FA0 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FA0?
You can download the ZB4FA0 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FA0?
Schneider Electric
