Schneider Electric ZB4FA1 Metal Push Button
The flush-mounted metal push button head ZB4FA1 features a sleek round profile, white unmarked operator, and durable chromium-plated bezel. Designed for harsh industrial environments, it boasts an IP69K protection rating, and rugged construction with a mechanical durability of 10 million cycles. Suitable for various control panels, it operates reliably within -40°C to +70°C, supporting overvoltage categories IEC Class 2 and UL type standards. Its compact size, easy mounting, and high resistance to vibration and shocks make it ideal for demanding automation applications.
Schneider Electric ZB4FA1 Metal Push Button Specifications:
- Material: Chromium plated metal bezel
- Shape: Round
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.22 in (31 mm)
- Mechanical durability: 10,000,000 cycles
- Ambient temperature (operation/storage): -40°C to +70°C (-40°F to +158°F)
- Protection ratings: IP66, IP67, IP69K, Type 13, 12, 4, 4X UL 50E
- Impact/shock resistance: 30 gn (18 ms), 50 gn (11 ms), 25 gn (6 ms, 1000 shocks)
- Vibration resistance: 5 gn (10-500 Hz), 25 mm peak to peak (2-10 Hz)
- Environmental certifications: UL Listed, CSA, CE, EAC
- Standards compliance: IEC 60947-5-1, IEC 60947-5-4, UL 508
Buy the Buy Schneider Electric ZB4FA1 Part Number ZB4FA1 Online
Discover the durable metal push button ZB4FA1, designed for industrial control panels. Its robust round construction features a white unmarked operator, high IP69K rating, and durability up to 10 million cycles. Suitable for harsh environments, it operates reliably from -40°C to +70°C, resists vibration and shocks, and complies with IEC and UL safety standards. Perfect for automation and machinery where reliability, protection, and long service life are critical. Purchase online now for immediate deployment in your industrial systems.
Get Schneider Electric ZB4FA1 today—built for demanding industrial control and long-lasting durability.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FA1?
You can click on the BUY or RFQ button to purchase ZB4FA1 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FA1?
You can download the ZB4FA1 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FA1?
Schneider Electric
